Denon AVR-1604 Service Manual

48
48
AVR-1604/684 / AVC-1580
C841 963 9006 405 Electrolytic 2.2uF/50V
C842-853 963 9004 708 Ceramic chip 0.1uF/50V
C854,855 963 9006 324 Electrolytic 100uF/25V
C856-864 963 9004 708 Ceramic chip 0.1uF/50V
C864L,R 963 9006 421 Electrolytic 47uF/16V
C865 960 9009 856 Ceramic chip 0.022uF/50V
C865L,R 963 9005 723 Ceramic chip 120pF/50V
C866 963 9004 708 Ceramic chip 0.1uF/50V
C868,869 963 9005 998 Ceramic chip 24pF/50V
C869L,R 963 9004 575 Ceramic chip 100pF/50V
C870 963 9004 698 Ceramic chip 0.01uF/50V
C871,872 963 9004 708 Ceramic chip 0.1uF/50V
C871L,R 963 9009 500 Mylar film 0.001uF/100V
C873-875 963 9004 698 Ceramic chip 0.01uF/50V
C873C,FL,FR,SB,SL,SR,SW 963 9004 672 Ceramic chip 680pF/50V
C874C,FL,FR,SB,SL,SR,SW 963 9006 146 Ceramic chip 560pF/50V
C875C,FL,FR,SB,SL,SR,SW 963 9006 298 Electrolytic 10uF/35V
C876,877 963 9004 708 Ceramic chip 0.1uF/50V
C876C,FL,FR,SB,SL,SR,SW 960 9008 611 Mylar film 0.0033uF/100V
C880C,FL,FR,SB,SL,SR,SW 963 9006 298 Electrolytic 10uF/35V
C916 963 9004 708 Ceramic chip 0.1uF/50V
C917 963 9006 298 Electrolytic 10uF/35V
C925 963 9004 708 Ceramic chip 0.1uF/50V
C926 963 9006 298 Electrolytic 10uF/35V
C931 963 9004 698 Ceramic chip 0.01uF/50V
C937 963 9006 298 Electrolytic 10uF/35V
C938 963 9006 379 Electrolytic 1uF/50V
C939 963 9004 698 Ceramic chip 0.01uF/50V
C943 963 9006 366 Electrolytic 0.1uF/50V
C944 963 9004 698 Ceramic chip 0.01uF/50V
C946,947 963 9004 708 Ceramic chip 0.1uF/50V
C948,949 963 9006 298 Electrolytic 10uF/35V
C950 963 9004 708 Ceramic chip 0.1uF/50V
C951 963 9005 901 Electrolytic 470uF/10V
C952 963 9004 708 Ceramic chip 0.1uF/50V
C953 963 9006 298 Electrolytic 10uF/35V
C955 963 9004 708 Ceramic chip 0.1uF/50V
C957 963 9004 708 Ceramic chip 0.1uF/50V
C958 963 9006 324 Electrolytic 100uF/10V
C959 963 9006 298 Electrolytic 10uF/35V
C960 963 9004 708 Ceramic chip 0.1uF/50V
C961 963 9006 298 Electrolytic 10uF/35V
C962 963 9004 708 Ceramic chip 0.1uF/50V
C965 963 9004 708 Ceramic chip 0.1uF/50V
C966 963 9005 901 Electrolytic 470uF/10V
C967 963 9004 708 Ceramic chip 0.1uF/50V
OTHER PARTS GROUP
CB803 963 0050 502 Chip emifil
CB805-810 963 0050 502 Chip emifil
CN801 963 0086 107 16P connector socket (TUC-P)
CN802 963 0086 204 19P connector socket (TUC-P)
CN803 963 0097 206 8P connector socket (TUC-P)
JACK801 963 0052 500 1P pin jack
L802 963 0050 803 Inductor 4.7uH
Ref. No. Part No. Part Name Remarks New

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
