Denon AVR-2106 Brochure & Specs

■
Multi-Function Preset Memory Remote Controller with Glo-keys
■ DENON's Latest Surround Technology Faithfully Recreates the
Surround Sound Produced at the Dubbing Stage.
• DTS 96/24 Decoding for DVD-Video
• DTS-ES Discrete 6.1 and Matrix 6.1
• DTS NEO:6
• Dolby Digital EX
• Dolby Pro Logic IIx
■
5 Channel/ 7 Channel Stereo Mode
Denon's popular 7 Channel Stereo mode transforms your favourite 2-channel
sources such as CD, tape, stereo radio and stereo video sources into exciting sur-
round sound, free of delay effects and unnatural artifacts, from all 7 speakers. This 7
Channel Stereo mode was originally developed by Denon to enhance music lovers'
enjoyment with home theater ambience.
■
Adjustable Cross-Over Switching
The AVR-2106 supports subwoofer cross-over switching with a choice of 8 cross-over
frequencies: 40/60/80/100/120/150/200/250Hz. This lets you more accurately match
the performance characteristics of the subwoofer to the main speaker system.
■ XM Satellite Radio Ready with optional 'Connect and Play' antenna*
*Subsciption to XM services also required.
■ Component video circuits which maintain flat response up to 100MHz,
ensuring sharp image quality
■ Video Up/Down conversion function
(Composite <-> S-Video, Composite /S-Video-> Component)
■
Audio Delay Function (0 - 200 msec.)
■
Pure Direct mode, for the pure enjoyment of music in high-quality sound
Other features
■
Night Mode for not disturbing others
■
Function Rename
■
AC Inlet
■
Input Function Level
■
REC OUT Selector
■
Front Panel Inputs (with S-Video, Digital Optical Input)
■
Front A/B Speaker Terminals
■
High-grade 7 Channel Speaker Terminals (all ch)
■
RS-232C Port
■
Frequency Synthesis Tuning
• 56-Station AM/FM/XM Random Preset Memory Tuning
• Auto Preset Memory (AM/FM)
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: 905-475-4085 www.denon.ca
Denon Electronics (USA), LLC.
19C Chapin Road, Suite 205 Pine Brook, N.J. 07058-9385 USA
TEL: 973-396-0810 www.usa.denon.com
Denon Brand Company
Kayabacho Tower 14F 1-21-2 Shinkawa, Chuo-ku, Tokyo 104-0033, Japan
www.denon.com
16290805 A Printed in Japan
AVR-2106
Input/Output Terminals For Every A/V System
Audio Inputs
9 Analog Inputs
PHONO, CD, (TUNER), DVD/VDP, TV/DBS,
VCR-1, VCR-2, CDR/TAPE, V.AUX(FRONT)
6 Analog EXT. Inputs
FRONT L/R, CENTER, SURROUND L/R, SUBWOOFER
6 Digital Inputs
OPTICAL x 4 (incl. FRONT x 1)
COAXIAL x 2
Audio Outputs
1 Analog PRE OUT Terminals
7.1 ch
3 Analog REC OUT Terminals
VCR-1, VCR-2, CDR/TAPE
1 Digital Output
OPTICAL x 1
Video Inputs
3 Component Video Inputs
VIDEO1, VIDEO2, VIDEO3
5 Composite Inputs
DVD/VDP, TV/DBS, VCR-1, VCR-2, V.AUX(FRONT)
5 S-Video Inputs
DVD/VDP, TV/DBS, VCR-1, VCR-2, V.AUX(FRONT)
Video Outputs
1 Component Video Output
MONITOR
3 Composite Outputs
VCR-1, VCR-2, MONITOR
3 S-Video Outputs
VCR-1, VCR-2, MONITOR
Specifications
Power Amplifier Section
Rated output *THD figures are power amp stage values.
Front 100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
130 W + 130 W (6 ohms, 1 kHz, 0.7 % THD)
Center 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
130 W (6 ohms, 1 kHz, 0.7 % THD)
Surround 100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
130 W + 130 W (6 ohms, 1 kHz, 0.7 % THD)
Surround Back
100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
130 W + 130 W (6 ohms, 1 kHz, 0.7 % THD)
Preamplifier Section
Input sensitivity/Impedance
PHONO(MM) 2.5 mV/47 kohms
CD, DVD/VDP, TV/DBS, VCR-1, VCR-2, CDR/TAPE, V.AUX(FRONT)
200 mV/47 kohms
Output level/Load impedance
SUBWOOFER 1.2 V/10 kohms
CDR/TAPE, VCR-1, VCR-2 200 mV/47 kohms
Frequency response 10 Hz - 100 kHz (+1, -3 dB) (Tone Defeat On)
Signal-to-noise ratio 100 dB (IHF-A weighted) (Tone Defeat On)
Tone control Treble: ±6 dB at 10 kHz
Bass: ±6 dB at 100 Hz
FM Section
Tuning frequency range 87.5 - 107.9 MHz
Usable sensitivity 1.0 µV (11.2 dBf)
AM Section
Tuning frequency range 520 - 1710 kHz
Usable sensitivity 18 µV
General
Power supply AC 120 V, 60 Hz
Power consumption 5.3 A
Dimensions 17-3/32” (W) x 6-47/64” (H) x 16-27/64” (D)
434 (W) x 171 (H) x 417 (D) mm
Weight 29 lbs5oz
13.0 kg
*Design and specifications are subject to change without notice.
*”Dolby”, “Dolby Digital”, “Pro Logic II”, “Dolby Digital EX” and the double-D device are registered trademarks of Dolby Laboratories Licensing Corporation.
*DTS is registered trademarks of DTS Technology.
AVR2106_E3.qxd 05.8.17 14:33 Page 2

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
