Denon AVR-2113 Service Manual

193
Ref. No. Part No. Part Name Remarks Q'ty New
C408 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C408 00D2544583971 C,ELECT GE 85C 47UF-M/50V(ROB) 2113E2 D040470087140S
C410 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C410 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C412 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C413 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C415,416 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C418 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C419 00D9630324005 C,ELECT 100UF-M/100V D04010108C240S
C420 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C420 00D9630312402 C,ELECT 220UF-M/50V (Pb Free) 2113E2 D040221087140S
C421 nsp C,CERAMIC 100PF-J/50V D010101167160S
C422 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C423 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C423 963134501660S C,ELECT GE 85C 220UF-M/25V 2113E2 D040221084060S
C424 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C424 00D2544583971 C,ELECT GE 85C 47UF-M/50V(ROB) 2113E2 D040470087140S
C426 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C426 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C428 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C429 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C434 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C436 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C436 00D9630312402 C,ELECT 220UF-M/50V (Pb Free) 2113E2 D040221087140S
C437 nsp C,CERAMIC 100PF-J/50V D010101167160S
C438 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C439 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C439 963134501660S C,ELECT GE 85C 220UF-M/25V 2113E2 D040221084060S
C440 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C440 00D2544583971 C,ELECT GE 85C 47UF-M/50V(ROB) 2113E2 D040470087140S
C442 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C442 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C444 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C445 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C455 963134501660S C,ELECT GE 85C 220UF-M/25V 2113E2 D040221084060S
C450 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C452 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C452 00D2544574922 C,ELECT 100UF-M/50V (Pb Free) 2113E2 D040101087060S
C453 nsp C,CERAMIC 100PF-J/50V D010101167160S
C454 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C455 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C456 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C456 00D2544583971 C,ELECT GE 85C 47UF-M/50V(ROB) 2113E2 D040470087140S
C458 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C458 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C460 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C461 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C466 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C468 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C468 00D2544574922 C,ELECT 100UF-M/50V (Pb Free) 2113E2 D040101087060S
C469 nsp C,CERAMIC 100PF-J/50V D010101167160S
C470 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C471 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C471 963134501660S C,ELECT GE 85C 220UF-M/25V 2113E2 D040221084060S
C472 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C472 00D2544583971 C,ELECT GE 85C 47UF-M/50V(ROB) 2113E2 D040470087140S
C474 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C474 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
