Denon AVR-2113 Service Manual

194
Ref. No. Part No. Part Name Remarks Q'ty New
C476 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C477 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C479,480 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C482 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C484 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C484 00D2544574922 C,ELECT 100UF-M/50V (Pb Free) 2113E2 D040101087060S
C485 nsp C,CERAMIC 100PF-J/50V D010101167160S
C486 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C487 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C487 963134501660S C,ELECT GE 85C 220UF-M/25V 2113E2 D040221084060S
C488 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C488 00D2544583971 C,ELECT GE 85C 47UF-M/50V(ROB) 2113E2 D040470087140S
C490 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C490 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C492 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C493 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C498 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C500 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C500 00D2544574922 C,ELECT 100UF-M/50V (Pb Free) 2113E2 D040101087060S
C501 nsp C,CERAMIC 100PF-J/50V D010101167160S
C502 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C503 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C503 963134501660S C,ELECT GE 85C 220UF-M/25V 2113E2 D040221084060S
C504 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C504 00D2544583971 C,ELECT GE 85C 47UF-M/50V(ROB) 2113E2 D040470087140S
C506 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C506 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C508 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C509 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C511,512 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C513,514 00D9630338402 C,ELECT 330UF-M/6.3V D040331081050S
C515 00D9630324607 C,ELECT 47UF-M/10V (Pb Free) D040470082060S
OTHERS PARTS GROUP
BKT400 nsp BRACKET 0.8t/SCREW 4010210196100S
CN404 963612504740D CN,WIRE 2MM 170MM/5P L002171050080S
CP401 nsp CN.WAFER 13P STRAIGHT L101200101310S
CP402 nsp CN.WAFER 5P 5267-05A L102526700500S
CP403 nsp CN.WAFER 10P STRAIGHT L101200101010S
CP405 nsp CN.WAFER 3P 5267-03A L102526700300S
G400 nsp CN,WIRE 1P L000600010050S
G402 nsp CN,WIRE 1P L000600010050S
J538 nsp CN.WIRE 1P L045061000050S
TP401-407 nsp CN.WAFER 3P L101200100320S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
