Denon AVR-2113 Service Manual

196
Ref. No. Part No. Part Name Remarks Q'ty New
R4029 nsp R,METAL FILM 10K-J,1/4W C060103063050S
R4147 nsp 270K-J,1/16W-1608 1913E3, 2113CIE3 C20002746M160S
R4147 nsp 56K-J,1/16W-1608 2113E2, 2113E1C C20005636M160S
R4148,4149 nsp 2.2M-J,1/5W-52RE-AX
1913E3, 2113CIE3,
2113E1C
C00002256P520S
R4150 nsp 1M-J,1/5W-52RE-AX 1913E3, 2113CIE3 C00001056P520S
CAPACITORS GROUP
C4000 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4001 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C4002 nsp C,FILM P.PROPYLENE 2113E2 D02122306C050S
C4003 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4004 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C4005 nsp C,FILM P.PROPYLENE 2113E2 D02122306C050S
C4006,4007 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4008 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C4009 nsp C,FILM P.PROPYLENE 2113E2 D02122306C050S
C4010,4011 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4012 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C4013 nsp C,FILM P.PROPYLENE 2113E2 D02122306C050S
C4014 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C4015 nsp C,FILM P.PROPYLENE 2113E2 D02122306C050S
C4016,4017 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4018 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C4019 nsp C,FILM P.PROPYLENE 2113E2 D02122306C050S
C4020 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4021 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C4022 nsp C,FILM P.PROPYLENE 2113E2 D02122306C050S
C4023-4025 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4027 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4028 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4030 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4032 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4035 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4038 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4041 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4044 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4047 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4049 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C4050,4051 nsp C,FILM 0.1UF-K/250V D02010407H080S
C4050,4051 nsp C,FILM P.PROPYLENE 2113E2 D02110406C050S
C4052 963134501800D C,ELECT GE 85C 10000UF-M/71V D040103089220S
C4053 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4054 963134501800D C,ELECT GE 85C 10000UF-M/71V D040103089220S
C4057 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C4059 963134011290S C,ELECT 4700UF-M/16V D040472083020S
C4060,4061 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4062 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C4063 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4064 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C4064 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C4065 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
