Denon AVR-2113 Service Manual

197
Ref. No. Part No. Part Name Remarks Q'ty New
C4066 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C4066 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C4067 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C4068 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C4068 963134001860S C,ELECT 470UF-M/16V 2113E2 D040471083080S
C4070 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4076 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4077-4081 nsp C,CERAMIC 100PF-J/50V D010101167160S
C4082 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4086 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C4093 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C4094 nsp C,CERAMIC 330PF-J/50V D010331167160S
C4095,4096 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C4097 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C4104 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C4111 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
z
C4140,4141 963134011730S C,CERAMIC DE1B3KX471KB4BL01 D00847127H010S
z
C4142 963132011940S C,CERAMIC DE2F3KY103MB3BM02 D008103589010S
C4143 nsp C,FILM 0.1UF-K/275V D02110407H010S
C4145-4147 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C4151 943134501590S C,ELECT GE 105C 100UF-M/200V D04110108G000S
z
C4148,C4149 963132011940S C,CERAMIC DE2F3KY103MB3BM02 2113E2, 2113E1C D008103589010S
C4150 nsp C,CERAMIC 0.1UF-K/25V 2113E2, 2113E1C D011104774161S
C4151 963134010200S C,ELECT 100UF-M/400V D04110108K000S
C4152 963134010210S C,ELECT 47UF-M/25V D041470084050S
C4153 963132010120S C,CERAMIC DEHR33A102KB2B D00810207Q010S
C4154 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C4155 963134010190S C,ELECT 10UF-M/50V D041100087050S
z
C4156 963132011930S C,CERAMIC DE1E3KX222MB4BL01 D00822248H010S
C4159,4160 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C4161 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C4162 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C4164,4165 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C4166 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
OTHERS PARTS GROUP
BD4000 nsp COIL,BEAD CBW160808U121T D340160811210S
BKT4140 nsp BRACKET 0.8t/SCREW
1913E3, 2113CIE3,
2113E1C
4010210196100S
BKT4141 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT4142 nsp BRACKET SCREW 4010210196000S
BKT4143 nsp BRACKET t1.0+Sn plating /PCB MTG 4010214876000S
CN4000 nsp CN,WIRE 160MM/5P 5264-05 L000161050080S
CN4001 nsp CN,WIRE 260MM/3P 5264-03 L000261030110S
CN4002 nsp
CN,WIRE 2MM 120MM/10P 20010HS-
10
L002121102620S
CN4141 nsp CN,WIRE 330MM/5P SMH250-05 L000331050110S
CP4000 nsp CN.WAFER 7.92MM 35328-0360 L108353280360S
CP4001 nsp CN,WAFER C125Z1-13 13P L109012511320S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
