Denon AVR-2113 Service Manual

207
Ref. No. Part No. Part Name Remarks Q'ty New
R1017,1018 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1019-1021 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1024-1032 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1033,1034 nsp R,CHIP 33-J, 1/16W C20003306M101S
R1036 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R1037 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1039 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1041 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1043 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1045 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1202 nsp R,CHIP 0-J,1/16W C20000006M101S
R1204 nsp R,CHIP 0-J,1/16W C20000006M101S
R1205 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1207,1208 nsp R,CHIP 0-J,1/16W C20000006M101S
R1210,1211 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1212,1213 nsp R,CHIP 0-J,1/16W C20000006M101S
R1217 nsp R,CHIP 0-J,1/16W C20000006M101S
R1301,1302 nsp R,CHIP THICK 24-D,1/16W-1608REEL C20002401M160S
R1303 nsp R,CHIP 0-J,1/16W C20000006M101S
R1305 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1306-1309 nsp R,CHIP THICK 24-D,1/16W-1608REEL C20002401M160S
R1310 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1311,1312 nsp R,CHIP 0-J,1/16W C20000006M101S
R1313 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1314,1315 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1317 nsp R,CHIP 0-J,1/16W C20000006M101S
R1318 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R1319,1320 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1323 nsp R,CHIP THICK 680-J,1/16W-1005REEL C20006816M101S
R1329 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1331 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1333 nsp R,CHIP THICK 680-J,1/16W-1005REEL C20006816M101S
R1334,1335 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1336-1338 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1339,1340 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1342-1344 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1345 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1350 nsp R,CHIP THICK 0-J,1/10W C200000060200S
R1352 nsp R,CHIP THICK 470-D,1/16W-1608REEL C20004711M160S
R1358,1359 nsp R,CHIP 0-J,1/16W C20000006M101S
R1360 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1401,1402 nsp R,NETWORK A-TYPE 10-J 1/16W C180100042100S
R1403,1404 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R1405,1406 nsp R,NETWORK A-TYPE 10-J 1/16W C180100042100S
R1407-1409 nsp R,NETWORK A-TYPE 4.7K-J 1/16W C180472042100S
R1410-1412 nsp R,NETWORK A-TYPE 47K-J 1/16W C180473042100S
R1413-1417 nsp R,NETWORK A-TYPE 4.7K-J 1/16W C180472042100S
R1418,1419 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1617,1618 963122500030D R,CHIP THICK 1K-D,1/16W-1608REEL C20001021M160S
R1619,1620 nsp CHIP RES. 1K-D 1/16W-1608REEL 1913E3 C20001021M161S
R1619,1620 nsp CHIP RES. 470-D 1/16W 1608REEL
2113CIE3, 2113E2,
2113E1C
C20004711M161S
R1622 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1628 nsp R, CHIP 2.7K-F, 1/16W
2113CIE3, 2113E2,
2113E1C
C20002724M161S
R1629 nsp CHIP RES. 180-F,1/16W-1608REEL
2113CIE3, 2113E2,
2113E1C
C20001814M161S
R1630 nsp R, CHIP 2.7K-F, 1/16W
2113CIE3, 2113E2,
2113E1C
C20002724M161S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
