Denon AVR-2113 Service Manual

208
Ref. No. Part No. Part Name Remarks Q'ty New
R1631 nsp CHIP RES. 180-F,1/16W-1608REEL
2113CIE3, 2113E2,
2113E1C
C20001814M161S
R1632 nsp R,CHIP 33-J, 1/16W C20003306M101S
R1635,1636 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1639 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R1640 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1641 nsp CHIP RES. 1.8K-J 1/16W-1005REEL C20001826M101S
R1642 nsp R,CHIP THICK 0-J,1/10W C200000060200S
R1645,1646 nsp R,CHIP 33-J, 1/16W C20003306M101S
R1647 nsp R,CHIP 0-J,1/16W C20000006M101S
R1648 nsp CHIP RES. 1.8K-J 1/16W-1005REEL C20001826M101S
R1649-1652 nsp R,CHIP 0-J,1/16W C20000006M101S
R1653 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1656 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1657 nsp R,CHIP 33-J, 1/16W C20003306M101S
R1659 nsp R,CHIP 0-J,1/16W C20000006M101S
R1660 nsp R,NETWORK A-TYPE 10-J 1/16W C180100042100S
R1661 nsp R,CHIP 0-J,1/16W C20000006M101S
R1662 nsp R,CHIP 33-J, 1/16W C20003306M101S
R1663-1665 nsp CHIP RES. 47-J 1/16W-1005REEL C20004706M101S
R1667-1670 nsp CHIP RES. 47-J 1/16W-1005REEL C20004706M101S
R1673 nsp R,NETWORK A-TYPE 47-J 1/16W C180470042100S
R1675-1679 nsp R,NETWORK A-TYPE 47-J 1/16W C180470042100S
R1681-1689 nsp R,NETWORK A-TYPE 47-J 1/16W C180470042100S
R1691-1694 nsp R,NETWORK A-TYPE 4.7K-J 1/16W C180472042100S
R1695 nsp CHIP RES. 56-J 1/16W-1005REEL C20005606M101S
R1699,1700 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1701 nsp R,NETWORK A-TYPE 10-J 1/16W C180100042100S
R1720-1728 nsp R,CHIP 0-J,1/16W C20000006M101S
R1729-1732 nsp R,NETWORK A-TYPE 0-J*2 1/16W C180000022100S
R1818,1819 nsp R,CHIP THICK 1K-D,1/16W-1608REEL C20001021M160S
R1820,1821 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2003 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2004 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R2006 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2008 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2011 nsp CHIP RES. 47-J 1/16W-1005REEL C20004706M101S
R2012 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2014,2015 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2016,2017 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2018 nsp 10-J,1/16W-1005REEL C20001006M101S
R2019 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2020 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2021 nsp CHIP RES. 1M-J 1/16W-1005REEL C20001056M101S
R2022 nsp CHIP RES. 47-J 1/16W-1005REEL C20004706M101S
R2023 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2024,2025 nsp R,CHIP 0-J,1/16W C20000006M101S
R2026 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2027 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2028 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2030 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2031 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2032 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2033 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2034 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2035 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2036 nsp R,CHIP 10K-J,1/16W C20001036M111S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
