Denon AVR-2113 Service Manual

209
Ref. No. Part No. Part Name Remarks Q'ty New
R2037 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2039 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2040 nsp R,CHIP 0-J,1/16W C20000006M101S
R2041 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2043 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2044 nsp R,CHIP 0-J,1/16W C20000006M101S
R2045 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2046 nsp R,CHIP 0-J,1/16W C20000006M101S
R2048,2049 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2101 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R2103-2106 nsp R,NETWORK A-TYPE 10-J 1/16W C180100042100S
R2107-2112 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R2113-2118 nsp R,NETWORK 10K-J*4 1/16W C180103042100S
R2119,2120 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R2201 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R2202,2203 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2204-2207 nsp CHIP RES. 150-J 1/16W-1005REEL C20001516M101S
R2208 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2209 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R2210,2211 nsp CHIP RES. 470J 1/16W1005REEL C20004716M101S
R2213 nsp R,CHIP 0-J,1/16W C20000006M101S
R2214 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R2215 nsp R,CHIP THICK 330K-J,1/16W-1005REEL C20003346M101S
R2216 nsp CHIP RES. 47KJ 1/16W-1005REEL C20004736M101S
R2217 nsp R,CHIP THICK 330K-J,1/16W-1005REEL C20003346M101S
R2220 nsp R,NETWORK 10K-J*4 1/16W C180103042100S
R2221 nsp CHIP 0-J,1/16W-1005REEL C20000006M101S
R2223 nsp CHIP RES. 1M-J 1/16W-1005REEL C20001056M101S
R2224 nsp CHIP RES. 820-J 1/16W-1005REEL C20008216M101S
R2225 nsp CHIP RES. 220-J 1/16W-1005REEL C20002216M101S
R2227-2233 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2234 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R2235 nsp R,CHIP THICK 330K-J,1/16W-1005REEL C20003346M101S
R2236-2238 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2240-2243 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2245-2255 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2257-2262 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2264 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2265-2268 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2269,2270 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2271-2274 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R2275 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2276 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R2277,2278 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2402 nsp R,CHIP 0-J,1/16W C20000006M101S
R2403 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2404 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R2405 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2406,2407 nsp CHIP RES. 470J 1/16W1005REEL C20004716M101S
R2410,2411 nsp CHIP RES. 100KJ 1/16W1005REEL C20001046M101S
R2412 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R2501 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2502 nsp R,CHIP 0-J,1/16W C20000006M101S
R2604 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2605-2608 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2609-2611 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2612 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R2613 nsp R,CHIP 10K-J,1/16W C20001036M111S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
