Denon AVR-2113 Service Manual

210
Ref. No. Part No. Part Name Remarks Q'ty New
R2615-2617 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2618 nsp R,CHIP THICK 13K-D,1/16W-1608REEL C20001331M160S
R2620 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2621 nsp CHIP RES. 1M-J 1/16W-1005REEL C20001056M101S
R2622 nsp CHIP RES. 1.5K-J 1/16W-1005REEL C20001526M101S
R2623-2626 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2629,2630 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2631,2632 nsp 10-J,1/16W-1005REEL C20001006M101S
R2633 nsp R,CHIP 0-J,1/16W C20000006M101S
R2634 nsp CHIP RES. 2.7K-J 1/16W-1005REEL C20002726M101S
R2635 nsp CHIP RES. 1.5K-J 1/16W-1005REEL C20001526M101S
R2636 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2640 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2641-2644 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2646 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2647 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2650 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2651,2652 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2653 nsp R,CHIP 0-J,1/16W C20000006M101S
R2701-2703 nsp R,NETWORK 10K-J*4 1/16W C180103042100S
R2704-2706 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R2707 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2708 nsp R,NETWORK 10K-J*4 1/16W C180103042100S
R2709-2718 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R2719 nsp R,NETWORK A-TYPE 4.7K-J 1/16W C180472042100S
R2720 nsp R,NETWORK A-TYPE 33-J 1/16W C180330042100S
R2721 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2801 nsp R,CHIP 0-J,1/16W C20000006M101S
R2803 nsp R,CHIP THICK 10-F,1/16W-1005REEL C20001004M100S
R2805,2806 nsp R,CHIP 0-J,1/16W C20000006M101S
R2812-2816 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2817 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R2819 nsp R,CHIP 33-J, 1/16W C20003306M101S
R2820 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2822-2825 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2826 nsp R,CHIP THICK 1.5K-F,1/16W-1005REEL C20001524M100S
R2827 nsp CHIP RES. 1.5K-J 1/16W-1005REEL C20001526M101S
R2828 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2829,2830 nsp R,CHIP THICK 49.9-F,1/16W-1608REEL C20049R94M161S
R2831 nsp R,CHIP THICK 8.2K-F,1/16W-1005REEL C20008224M101S
R2832,2833 nsp R,CHIP THICK 49.9-F,1/16W-1608REEL C20049R94M161S
R2834 nsp R,CHIP THICK 3.9K-F,1/16W-1005REEL C20003924M100S
R2835,2836 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R2837 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2838,2839 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R2841-2844 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R2845,2846 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R2849 nsp R,CHIP 10K-J,1/16W C20001036M111S
R2850 nsp R,CHIP 0-J,1/16W C20000006M101S
R2851 nsp CHIP RES. 4.7-J 1/16W-1005REEL C2004R706M101S
R2852,2853 nsp 10-J,1/16W-1005REEL C20001006M101S
R2854-2856 nsp R,CHIP 0-J,1/16W C20000006M101S
R2859 nsp R,CHIP 0-J,1/16W C20000006M101S
R2863 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3003 nsp CHIP RES. 1KJ 1/16W1005REEL 2113CIE3 C20001026M101S
R3004 nsp CHIP RES. 3.3KJ 1/16W1005REEL 2113CIE3 C20003326M101S
R3005 nsp CHIP RES. 2.2K-J 1/16W-1005REEL 2113CIE3 C20002226M101S
R3009 nsp CHIP RES. 100KJ 1/16W1005REEL 2113CIE3 C20001046M101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
