Denon AVR-2113 Service Manual

211
Ref. No. Part No. Part Name Remarks Q'ty New
R3017 nsp CHIP RES. 18K-J 1/16W-1608 1913E3 C20001836M160
R3017 nsp CHIP RES. 10K-J 1/16W-1608REEL 2113E1C C20001036M160S
R3018 nsp CHIP RES. 3.3K-J 1/16W-1608REEL 1913E3 C20003326M160S
R3018 nsp CHIP RES. 0-J 1/16W-1608REEL 2113CIE3 C20000006M160S
R3018 nsp CHIP RES. 10K-J 1/16W-1608REEL 2113E1C C20001036M160S
R3019-3022 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3023 nsp R,CHIP 0-J,1/16W C20000006M101S
R3024-3029 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3030,3031 nsp R,CHIP 0-J,1/16W C20000006M101S
R3032-3034 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3035 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3037 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3038 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3042,3043 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3044 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3045,3046 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3048 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3050 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3051 nsp R,CHIP 0-J,1/16W C20000006M101S
R3058-3064 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3065-3067 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R3068 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3069 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3070-3076 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3077,3078 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3084 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3086 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3088 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3090 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3092 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3094 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3098 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3100 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3201 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3202 nsp CHIP RES. 2.2MJ 1/16W1005REEL C20002256M101S
R3203 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3204 nsp CHIP RES. 100KJ 1/16W1005REEL C20001046M101S
R3205 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R3206 nsp CHIP RES. 100KJ 1/16W1005REEL C20001046M101S
R3207 nsp CHIP RES. 220KJ 1/16W1005REEL C20002246M101S
R3208 nsp CHIP RES. 27K-J 1/16W-1005REEL C20002736M101S
R3209 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R3211 nsp CHIP RES. 1.2K-J 1/16W-1005REEL C20001226M101S
R3212,3213 nsp R,CHIP 0-J,1/16W C20000006M101S
R3214 nsp CHIP RES. 0-J 1/16W-1608REEL 2113CIE3 C20000006M160S
R3215 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3216,3217 nsp R,CHIP 33-J, 1/16W C20003306M101S
R3218 nsp CHIP RES. 0-J 1/16W-1608REEL 2113CIE3 C20000006M160S
R3219 nsp CHIP RES. 390J 1/16W1005REEL C20003916M101S
R3220 nsp CHIP RES. 100KJ 1/16W1005REEL C20001046M101S
R3221 nsp CHIP RES. 2.7K-J 1/16W-1005REEL C20002726M101S
R3222 nsp CHIP RES. 270-J 1/16W-1005REEL C20002716M101S
R3223 nsp R,CHIP THICK 470K-J,1/16W-1005REEL C20004746M101S
R3224 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3225 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R3226 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3227 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R3228 nsp CHIP RES. 100KJ 1/16W1005REEL C20001046M101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
