Denon AVR-2113 Service Manual

212
Ref. No. Part No. Part Name Remarks Q'ty New
R3230 nsp R,CHIP THICK 16K-J,1/16W-1005REEL C20001636M101S
R3231 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3232 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3234 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3235 nsp R,CHIP THICK 120K-J,1/16W-1005REEL C20001246M101S
R3237 nsp CHIP RES. 470J 1/16W1005REEL C20004716M101S
R3238 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3239,3240 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3241 nsp CHIP RES. 390J 1/16W1005REEL C20003916M101S
R3242 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3243 nsp CHIP RES. 2.7K-J 1/16W-1005REEL C20002726M101S
R3244 nsp CHIP RES. 270-J 1/16W-1005REEL C20002716M101S
R3245 nsp R,CHIP THICK 120K-J,1/16W-1005REEL C20001246M101S
R3247 nsp CHIP RES. 470J 1/16W1005REEL C20004716M101S
R3248 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R3249 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3250 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3251 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R3252 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3401 nsp R,CHIP 0-J,1/16W C20000006M101S
R3601 nsp R,CHIP 0-J,1/16W C20000006M101S
R3602 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3603-3605 nsp R,CHIP 0-J,1/16W C20000006M101S
R3607 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3609-3611 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3625 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3626 nsp R,CHIP THICK 47K-D,1/16W-1608REEL C20004731M160S
R3627 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3628 nsp R,CHIP THICK 120K-D,1/16W-1608REEL C20001241M160S
R3629 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3631 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3632 nsp R,CHIP THICK 300K-D,1/16W-1608REEL C20003041M160S
R3633 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3634 nsp R,CHIP THICK 120K-D,1/16W-1608REEL C20001241M160S
R3645,3646 nsp R,CHIP THICK 0-J,1/10W C200000060200S
R3647 nsp R,CHIP 0-J,1/16W C20000006M101S
R3649-3660 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3661,3662 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R3663,3664 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3666,3667 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3669 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3670,3671 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R3672 nsp R,CHIP 0-J,1/16W C20000006M101S
R3673,3674 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R3676 nsp CHIP RES. 3.3KJ 1/16W1005REEL C20003326M101S
R3677 nsp R,CHIP 10K-J,1/16W C20001036M111S
R3678 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R3679 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R3680 nsp CHIP RES. 100KJ 1/16W1005REEL C20001046M101S
R3681 nsp CHIP RES. 100J 1/16W1005REEL C20001016M101S
R3687,3688 nsp CHIP RES. 22-J 1/16W-1005REEL C20002206M101S
R3689-3702 nsp R,CHIP 0-J,1/16W C20000006M101S
CAPACITORS GROUP
C1003-1007 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1010 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1016 nsp C,CERAMIC 1000PF-K/50V D011102177101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
