Denon AVR-2113 Service Manual

213
Ref. No. Part No. Part Name Remarks Q'ty New
C1023 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1025 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1027 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1029 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1031 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1201-1207 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1208 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1209 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1210 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1211 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1212 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1219 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1301-1304 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1305 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1306-1311 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1312 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1313 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1314-1321 nsp R,CHIP 0-J,1/16W C20000006M101S
C1323-1325 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1327 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1329-1331 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1333 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1335,1336 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1337 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1339 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1341 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1342 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1345 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1350 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1351 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1358 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1361 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1362 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1364 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1367 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1369 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1370 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1373 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1377 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1381 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1385 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1387,1388 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1391 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1393 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1395 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1396 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1398 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1401 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1402 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1407 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1410 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1411 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1412 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1415 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1416 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1418 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1419 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1420,1421 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
