Denon AVR-2113 Service Manual

214
Ref. No. Part No. Part Name Remarks Q'ty New
C1424 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1425 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1429 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1430 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1431 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1434,1435 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1439,1440 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1441 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1443,1444 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1445 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1446,1447 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1448 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1449 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1450,1451 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1452,1453 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1454-1461 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1462,1463 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1464 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1465 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1466 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1467 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1468,1469 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1470 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1472 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1474,1475 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1476 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1477,1478 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1479 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1480 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1481 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1482 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1484 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1485 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1486-1489 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1490 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1491 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1492 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1494 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1495-1498 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1500 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C1511,1512 nsp C,CERAMIC 8PF-D/50V D010080117160S
C1513 nsp C,CERAMIC 1UF-K/10V D011105772161S
C1514 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1516,1517 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1605,1606 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1607-1609 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1610 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1611-1613 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1614,1615 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1616-1620 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1621 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1622,1623 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1624 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1625 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1626-1632 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1633 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1634 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1635 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
