Denon AVR-2113 Service Manual

215
Ref. No. Part No. Part Name Remarks Q'ty New
C1636 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1637 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1639 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1640 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1642 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1643,1644 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1645 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1647 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1649 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1651,1652 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1653,1654 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1656,1657 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1659,1660 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1661,1662 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1663,1664 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1665 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1666 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1667 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1668,1669 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1670,1671 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1672 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1673,1674 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1675 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1676 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1677 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1678 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1679 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1680 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1681,1682 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1683 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1690 ,
C1692
nsp C,CERAMIC 0.15uF-K/10V-1608REEL D011154172160S
C1691 ,
C1693
nsp C,CERAMIC 0.012uF-K/50V-1608REEL D011123177161S
C1694 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1697 nsp C,CERAMIC 4.7UF-K/6.3V 1913E3 D011475571160S
C1698,1699 nsp C,CERAMIC 0.1UF-K/50V 1913E3 D011104177101S
C1700 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1702,1703 nsp C,CERAMIC COG7PF-D/50V D010070117160S
C1704 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1705,1706 nsp C,CERAMIC 1UF-K/10V D011105772161S
C1707 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1709,1710 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1711 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1712 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1713 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1721 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1730 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1801 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1810-1825 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1826 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1835-1851 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1853 nsp C,CERAMIC 1UF-K/10V D011105772161S
C1854 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2001 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2002 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2003 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2004 nsp C,CERAMIC 0.1UF-K/50V D011104177101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
