Denon AVR-2113 Service Manual

217
Ref. No. Part No. Part Name Remarks Q'ty New
C2086 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2087 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2088-2092 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2093 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2094 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2095 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2096 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2097 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2098 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2099 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2100 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2101 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2102 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2103-2106 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2107 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2108 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2109 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2110,2111 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2112 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2113,2114 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2115 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2203-2205 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2206,2207 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C2208-2210 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2211,2212 nsp C,CERAMIC 12PF-J/50V D011120167101S
C2213,2214 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2215 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2216 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2217 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2219 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2220 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2221 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C2222-2226 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2228 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2230-2237 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2238 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C2239 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2401-2405 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2406 nsp C,CERAMIC 2.2UF-M/6.3V-1005REEL D011225581100S
C2407 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2408 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2409,2410 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2411 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2412 nsp C,CERAMIC 2.2UF-M/6.3V-1005REEL D011225581100S
C2413 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2415,2416 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2417 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2418 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2419 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2420,2421 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2422-2425 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2426 00D9630338606 C,ELECT 10UF-MVG/16V D050100083470S
C2427-2432 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2435,2436 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2437,2438 nsp C,CERAMIC 2200PF-K/50V D011222177101S
C2439-2445 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2447 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2448 nsp C,CERAMIC 0.1UF-K/50V D011104177101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
