Denon AVR-2113 Service Manual

218
Ref. No. Part No. Part Name Remarks Q'ty New
C2450 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2451 963134000450S C,ELECT 100UF-MVG/16V D050101083660S
C2454-2461 nsp C,CERAMIC X7R3900PF-K/50V D011392777160S
C2454-2461 nsp
C,CERAMIC CHIP T.C CH)3900PF-K/50V-
1608REEL
2113E2 D010392177163S
C2465-2468 nsp C,CERAMIC 680pF-J 50V D010681167160S
C2465-2468 nsp
C,CERAMIC CHIP T.C CH)680PF-J/50V-
1608REEL
2113E2 D010681167163S
C2469,2470 nsp C,CERAMIC 470PF-J/50V D010471167160S
C2469,2470 nsp
C,CERAMIC CHIP T.C CH)470PF-J/50V-
1608REEL
2113E2 D010471167163S
C2471-2476 nsp C,CERAMIC 680pF-J 50V D010681167160S
C2471-2476 nsp
C,CERAMIC CHIP T.C CH)680PF-J/50V-
1608REEL
2113E2 D010681167163S
C2477,2478 nsp C,CERAMIC 470PF-J/50V D010471167160S
C2477,2478 nsp
C,CERAMIC CHIP T.C CH)470PF-J/50V-
1608REEL
2113E2 D010471167163S
C2479,2480 nsp C,CERAMIC 680pF-J 50V D010681167160S
C2479,2480 nsp
C,CERAMIC CHIP T.C CH)680PF-J/50V-
1608REEL
2113E2 D010681167163S
C2481,2482 00D9630338606 C,ELECT 10UF-MVG/16V D050100083470S
C2483,2484 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C2486 963134000450S C,ELECT 100UF-MVG/16V D050101083660S
C2488 963134000450S C,ELECT 100UF-MVG/16V D050101083660S
C2601 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2602,2603 nsp C,CERAMIC 12PF-J/50V D011120167101S
C2605-2608 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2609-2619 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2620-2622 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2623 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2624 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2627-2630 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2631-2640 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2641-2643 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2645 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2648 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2652,2653 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2657 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2659 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2660-2667 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2676,2677 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2678 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2679,2680 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2801 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C2803 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2806 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2807,2808 nsp C,CERAMIC 10PF-D/50V D011100117101S
C2811 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2812 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2813 nsp C,CERAMIC 470PF-K/50V D011471177101S
C2814 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2815 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2816 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C2817 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2818 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C2819 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2821 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2823 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2824-2828 nsp C,CERAMIC 0.1UF-K/50V D011104177101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
