Denon AVR-2113 Service Manual

219
Ref. No. Part No. Part Name Remarks Q'ty New
C2829 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2831 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2832 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2833 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2834 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2842-2845 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2846 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2850 nsp C,CERAMIC 0.001UF-J/50V D010102167160S
C2851,2852 nsp C,CERAMIC 0.001UF-J/50V D010102167160S
C2851,2852 nsp C,CERAMIC 330PF-J/50V 2113E2 D010331167160S
C2853 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3001 ,
C3003
nsp C,CERAMIC 1000PF-K/50V 2113CIE3 D011102177101S
C3002 nsp C,CERAMIC 0.1UF-K/16V 2113CIE3 D011104177101S
C3009 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3010 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C3011-3014 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3015,3016 nsp C,CERAMIC 12PF-J/50V D011120167101S
C3017-3019 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3021,3022 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3202 nsp C,CERAMIC 220PF-K/50V D011221177101S
C3205,3206 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3209 nsp C,CERAMIC 0.1UF-K/50V
2113CIE3, 2113E2,
2113E1C
D011104177101S
C3210 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3211 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C3212 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3213-3216 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C3414-3416 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C3417 nsp C,CERAMIC 100PF-J/50V D011101167101S
C3418 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C3419-3424 nsp C,CERAMIC 100PF-J/50V D011101167101S
C3601-3605 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3619-3623 nsp C,CERAMIC 10UF-K/16V D011106573200S
C3625-3629 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C3631-3635 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3637-3641 nsp C,CERAMIC 10UF-K/16V D011106573200S
C3643-3647 nsp C,CERAMIC 10UF-K/16V D011106573200S
C3649-3653 nsp C,CERAMIC 15PF-J/50V D010150167160S
C3667-3669 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C3673-3676 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3677 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C3678 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C3682 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C3695-3701 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3744 nsp C,CERAMIC 1UF-K/10V D011105772161S
C3752 nsp C,CERAMIC 1UF-K/10V D011105772161S
C3788 nsp C,CERAMIC X7R0.015UF-K/50V D011153777160S
C3789 00D9630325402 C,ELECT 470UF-MVG/6.3V D050471081200S
C3790 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3792 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3795 nsp C,CERAMIC 1UF-K/10V D011105772161S
C3797 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3799 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3802 963134501220S C,ELECT 470UF-MVG/6.3V (RV0) 2113E2 D050471081330S
C3804 nsp C,CERAMIC 0.1UF-K/50V D011104177101S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
