Denon AVR-2113 Service Manual

220
Ref. No. Part No. Part Name Remarks Q'ty New
OTHERS PARTS GROUP
L1201-1203 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L1301-1313 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1602 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1605-1615 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1616 nsp COIL,BEAD BLM21PG221SN1 1913E3 D340201212210S
L1617-1619 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L1801 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2601-2603 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2801,2802 nsp COIL,CHIP DLW21SN900HQ2L D311201219000S
L2804 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L2806 nsp COIL,CHIP DLW21SN181SQ2L D311201211810S
L2807-2810 nsp COIL,BEAD CBW201209U221T D340201202210S
L2812 nsp COIL,BEAD CBW160808U121T D340160811210S
L2813 nsp R,CHIP 0-J, 1/16W C20000006M160S
L2814,2815 nsp R,CHIP 0-J, 1/16W C20000006M160S
L2814,2815 nsp
COIL,CHIP LQM18PN1R5MFR 1.5UH
SMD(1608)-REEL
2113E2 D311160811520S
L3401-3404 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L3601-3610 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L3613-3622 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L3625-3627 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L3628 nsp COIL,BEAD CBW160808U121T D340160811210S
X1301 141810045507S CRYSTAL CHIP FCX-04(27MHz) E80527R000080S
X1601 141810045507S CRYSTAL CHIP FCX-04(27MHz) E80527R000080S
X2001 943141100020S CRYSTAL CHIP FCX-04(21.875MHz) E80521R875080S
X2201 141810046500S CRYSTAL CHIP FCX-04(24.576MHz) E80524R576080S
X2601 141810049509S CRYSTAL CHIP FCX-04(24MHz) E80524R000080S
X3001 00D3991038900 CRYSTAL CHIP FCX-03(12MHz) E805120000020S
K2201 963643003580S TER,RCA 1PIN G600107C0020YS
K3001 ,
K3002
00D9630244703 JACK,D3.5 EARPHONE 2113CIE3 G40130802000YS
N1001 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1002 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1003 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1004 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1201 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1202 nsp CN.FPC 23P L130100162330S
N1301 nsp CN.FPC 23P L130100162330S
N1302 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N1601 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N1602 963612504750D CN.WAFER AD3PBC19G0-T L109100190190S
N2001 nsp CN. FPC 1.0MM 1.0-16-10PB-2 10P L130100161030S
N2201 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N2601 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N2602 nsp CN.FPC 6P 1.0-16-6PB-2 L130100160630S
N2801 nsp CN.WAFER 5P 20010-05 L101200100510S
N2802 963643100130S JACK,MODULAR RJ45 G4060RJ450120S
N3001 nsp CN.FPC 7P 1.0-16-7PB-2 L130100160730S
N3002 nsp CN.FPC 11P L130100161130S
N3201 nsp CN.FPC 4P 1.0-9-4PW
2113CIE3, 2113E2,
2113E1C
L130100090450S
N3401 nsp CN,WAFER C125Z2-13 13P L109012521320S
N3402 nsp CN,WAFER C125Z2-09 9P L109012520920S
N3403 nsp CN.WAFER C125Z2-31 31P L109012523120S
N3404 nsp CN,WAFER C125Z2-07 7P L109012520720S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
