Denon AVR-2113 Service Manual

3.4. DIAGNOSTICMODE(Video/Audio(signal)pathconrmationmode)
This mode is used for conrming the Video and Audio (signal) paths. (Troubleshooting)
Conrming the operation of unit can be easily done after repair.
Backup data will not be lost.
3.4.1.Operation
Use the remote control (RC-1156) that is supplied with the AVRxx12 model. Press buttons on the remote control in the order indicated in the “Details of how to operate remote control” column in the following table to establish the conrmation path.
You will nd using another remote control unit with the macro functions very useful. To use the macro functions, program a macro function to output a remote control code in accordance with the steps in the table below.
3.4.2.Videosystemconrmationitems
g.XX : Refer to the block diagram of the g.XXth.
Conrmationitem Setting and display Detailsofhowtooperateremotecontroller*a)
Outputsequenceofremotecontrolcodes
※
Itisusefultoformamacroprogram.*b)
Contentsofconrmation Remarks
1
Analog Video (signal) Path Video Convert (IP Scaler) : OFF
All ZONE : ON
Display:
V 0 1 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : CVBS / Output : CVBS
·Input : USB (Picture) / Output : CVBS
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [1/./]
w
KEY 1/CODE1 (Main Zone)
Initialization
6.Press [ZONE SELECT], Select "ZONE2"
7.Press [ZONE ON]
e
ZONE2 POWER ON
8.Press [ZONE SELECT], Select "MAIN"
9.Press [DVD]
r
DVD (Main Zone)
2
Analog or HDMI to HDMI (signal) Path Video Convert (IP Scaler) : ON
IP Scaler : Analog&HDMI
Resolution : Auto
Display:
V 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input CVBS / Output : HDMI
·Input Component / Output : HDMI
·Input HDMI / Output : HDMI
·Input : USB (Picture) / Output : HDMI
(
b
As the input source, you can switch from DVD to other ones.)
Conrm the input pass one by one.
Because it becomes only the input of the highest input
becomes Convert/ (signal) Path if it inputs it at the same
time.
(HDMI input > Component input > CVBS input)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [2/ABC]
w
KEY 2/ABC (Main Zone)
Initialization
6.Press [ZONE SELECT], Select "ZONE2"
7.Press [ZONE ON]
e
ZONE2 POWER ON
8.Press [ZONE SELECT], Select "MAIN"
9.Press [DVD]
r
DVD (Main Zone)
3
GUI FUNCTION Video Convert (IP Scaler) : ON
IP Scaler : Analog&HDMI
Resolution : Auto
Menu : ON
All ZONE :ON
Display:
V 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·GUI Display / Output : HDMI
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [2/ABC]
w
KEY 2/ABC (Main Zone)
Initialization
6.Press [ZONE SELECT], Select "ZONE2"
7.Press [ZONE ON]
e
ZONE2 POWER ON
8.Press [ZONE SELECT], Select "MAIN"
9.Press [DVD]
r
DVD (Main Zone)
10.Press [AMP]
11.Press [MENU]
t
GUI MENU (Main Zone)
4
CEC FUNCTION
(Control Monitor : HDMI Monitor)
HDMI Control : ON
Display:
V 0 3 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF · When the power supply of a TV is put in the standby mode, make sure
that the power supply of this unit is also put in the standby mode.
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [3/DEF]
w
KEY 3/DEF (Main Zone)
Initialization & CEC Control ON
6.Press [DVD]
e
DVD (Main Zone)
5
HDMI Audio (signal) Path
(Audio : AMP)
Audio : AMP(When checking the audio output
from AMP)
Display:
V 0 5 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : HDMI (Signal of PCM, Dolby Digital or DTS) / Output : Speakers
·Input : HDMI (Signal of HD Audio) / Output : Speakers
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [5/JKL]
w
KEY 5/JKL (Main Zone)
Initialization & Select Audio AMP
6.Press [DVD]
e
DVD (Main Zone)
6
HDMI Audio (signal) Path
(Audio : TV)
Audio : TV(When checking the audio output
from TV)
Display:
V 0 6 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF · Input : HDMI (Signal of PCM or Dolby Digital or DTS) / Output : HDMI
(Audio output from connected TV)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [6/MNO]
w
KEY 6/MNO (Main Zone)
Initialization & Audio Select TV
6.Press [DVD]
e
DVD (Main Zone)
g.1
g.2
g.3
g.4
g.5
g.6
29
