Denon AVR-2113 Service Manual

3.4.3.Audiosystemconrmationitems
g.XX : Refer to the block diagram of the g.XXth.
Conrmationitem Setting and display Detailsofhowtooperateremotecontroller
Outputsequenceofremotecontrolcodes
b
Itisusefultoformamacroprogram.
Contentsofconrmation Remarks
1
Analog (signal) Path Input Mode : Fixed ANALOG
SURROUND mode : DIRECT
Amp assign : NORMAL
Display:
A 0 1 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [7/PQRS]
w
KEY 7/PQRS (Main Zone)
Initialization & Amp assign NORMAL& Input Mode
Fixed ANALOG & SURROUND mode DIRECT
8.Press [DVD]
r
DVD (Main Zone)
2
DIGITAL (signal) Path
(MAIN)
Input Mode : Fixed DIGITAL
Amp assign : NORMAL
Display:
A 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [8/TUV]
w
KEY 8/TUV (Main Zone)
Initialization & Amp assign NORMAL& Input Mode
Fixed DIGITAL
6.Press [DVD]
e
DVD (Main Zone)
3
HDMI (signal) Path Input Mode : Fixed HDMI
Amp assign : NORMAL
Display:
A 0 5 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : HDMI / Output : Speakers (Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [MOVIE]
w
MOVIE Select
Initialization &Amp assign NORMAL & Input Mode
Fixed HDMI
6.Press [DVD]
e
DVD (Main Zone)
4
A/D (signal) Path
(Main Zone)
Amp assign : NORMAL
SURROUND mode : Multi ch STEREO
Vol -20dB
Speaker Cong : SSSSY
(Front/Center/Surround/Sourround Back : Small, SW : Yes)
Display:
A 0 6 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : SW(20Hz)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [MUSIC]
w
MUSIC
Initialization &Amp assign NORMAL &
SURROUND mode : Multi ch STEREO & Volume
-20dB
6.Press [DVD]
r
DVD (Main Zone)
5
Amp Assign (signal) Path
(Amp Assign : ZONE2)
Amp assign : ZONE2
ZONE2 Function : Source
Zone2 Vol -20dB
Display:
A 0 7 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : LINE OUT(ZONE2 L/R) AVR-2113 model only
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [GAME]
w
GAME
Initialization & Amp assign ZONE2 &
SURROUND mode : Multi ch STEREO & ZONE2
Volume -20dB
6.Press [ZONE SELECT], Select "ZONE2"
7.Press [ZONE ON]
e
ZONE2 POWER ON
8.Press [ZONE SELECT], Select "MAIN"
9.Press [DVD]
r
DVD (Main Zone)
6
Amp Assign (signal) Path
(Amp Assign : BiAMP)
Amp assign : BiAMP
SURROUND mode : Multi ch STEREO
Vol -20dB
Display:
A 1 1 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "MAIN"
5.Press [
8
]
w
8
Initialization & Amp assign BiAMP & SURROUND
mode : Multi ch STEREO & Volume -20dB
6.Press [DVD]
e
DVD (Main Zone)
g.7
g.8
g.9
g.10
g.11
g.12
30

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
