REAR PANEL 1
Rear Panel (2 of 2)
6
RS-232C connector
The RS-232C serial port is provided to allow compatibility with an
external home automation controller. Consult the owner’s manual
of the home automation controller for more information about serial
control of this unit. The serial port allows two-way control and status
via an external home automation controller.
REMOTE CONTROL jacks
Used to connect infrared receivers/transmitters in order to operate
this unit and external devices from a different room.
Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
1
2
3
4 5
6
7
8
9
10
11
12
REMOTE CONTROL 1
