Denon AVR-2807 Control Protocol

- 11 -
EVENT PARAMETER
function example
TF UP TUNER Frequency UP/DOWN , direct change TFUP<CR>
DOWN TFDOWN<CR>
****** (6 digits) --- ****.** kHz at AM band (>050000 is AM.)
****.** MHz at FM band (<050000 is FM.)
TF105000<CR>
(1050.00kHz at AM)
XM*** (3 digits) --- *** CH at XM band (North America model Only) TFXM001<CR>
(XM001 CH at XM)
? Return TF Status TF?<CR>
TP UP TUNER PRESET CH UP/DOWN , direct change to No.** TPUP<CR>
DOWN TPDOWN<CR>
**(PRESET No.) TPA1<CR>
(PRESET No.”A1”)
? Return TP Status TP?<CR>
MEMORY TUNER PRESET MEMORY TPMEMORY<CR>
TM TUNER BAND , MODE Select
AM ---Band set to AM TMAM<CR>
FM ---Band set to FM TMFM<CR>
XM ---Band set to XM (North America model Only) TMXM<CR>
? Return TM Status TM?<CR>
AUTO ---Tuning mode set to AUTO mode TMAUTO<CR>
MANUAL ---Tuning mode set to MANUAL mode TMMANUAL<CR>
TF, TP, TM COMMAND : '*' parameters can NOT operate when INPUT source isn’t TUNER.

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
