AVR-5308CI / AVC-A1HD
116 P112/ISRXD1(UART) HDRADIO MIHDO I -
Lv
3V - - I O/L HD RADIO control
117 P111/ REMOTE/232C POWER O C
-
3V Ed Z O/L O/L REMOTE POWER/232C POWER control pin (ON : H)
118 P110/ISTXD1(UART) HDRADIO MOHDI O C
-
3V - Z O/L O/L HD RADIO control
119 P03/AN03/D3 D3 I/O C
-
3V - Z O/L O/L External memory access pin
120 P02/AN02/D2 D2 I/O C
-
3V - Z O/L O/L External memory access pin
121 P01/AN01/D1 D1 I/O C
-
3V - Z O/L O/L External memory access pin
122 P00/AN00/D0 D0 I/O C
-
3V - Z O/L O/L External memory access pin
123 P157/AN157 FL CLK O C
-
5V - Z O/L O/L FL DRIVER control pin
124 P156/AN156 FL DATA O C
-
5V - Z O/L O/L FL DRIVER control pin
125 P155/AN155 FL CE1 O C
-
5V - Z O/L O/L FL DRIVER control pin
126 P154/AN154 FL RST O C
-
5V Ed Z O/L O/L FL DRIVER control pin
127 P153/AN153 VSEL A I -
Lv
5V Eu Z O/L O/L Master Volume rotation detect input (Rotary encoder)
128 P152/AN152/ISRXD0 E SPI CS O C
-
5V Ed Z O/L O/L ETHERNET comm. control pin
129 P151/AN151/ISCLK0 E SPI CLK O C
-
5V Ed Z O/L O/L ETHERNET comm. control pin
130 VSS VSS - -
-
-----GND
131 P150/AN150/ISTXD0 E SPI MOEI O C
-
5V Ed Z O/L O/L ETHERNET comm. control pin
132 VCC VCC - -
-
5V - - - - +5V
133 P107/AN7/KI3
KEY4 I -
Lv
5V Eu Z I I Button input4
134 P106/AN6/KI2
KEY3 I -
Lv
5V Eu Z I I Button input3
135 P105/AN5/KI1
KEY2 I -
Lv
5V Eu Z I I Button input2
136 P104/AN4/KI0
KEY1 I -
Lv
5V Eu Z I I Button input1
137 P103/AN3 ISEL B I -
Lv
5V Eu Z O/L O/L Input selector rotation detect input (Rotary encoder)
138 P102/AN2 ISEL A I -
Lv
5V Eu Z O/L O/L Input selector rotation detect input (Rotary encoder)
139 P101/AN1 VSEL B I -
Lv
5V Eu Z O/L O/L Master Volume rotation detect input (Rotary encoder)
140 AVSS AVSS - -
-
- - - - - Analog GND
141 P100/AN0 MODE I -
Lv
5V - Z I O/L Destination switching input
142 VREF VREF - -
-
5V - - - - Ref. power supply input +5V
143 AVCC AVCC - -
-
5V - - - - Analog Power supply +5V
144 P97/ADTRG
/RXD4 (POA LINK RXD) I -
-
5V - Z I O/L (AVP-POA LINK comm. control pin for AVPA1HD)
Pin Pin Name Symbol I/O Type
Det
VCC Op(Ext.) Res STBY stop Function
Note: Pin No. : Terminal number of microcomputer.
Port Name : The name entered in the data sheet of microcomputer.
Symbol : Symbolized interface function.
I/O : Input or out of part.
“I” = Input port
“O” = Output port
Type : Composition of port in case of output port.
“C” = CMOS output
“N” = NMOS open drain output
“P” = PMOS open drain output
Op : Pull up/Pull down selection information.
“Iu” = Inner microcomputer pull up
“Id” = Inner microcomputer pull down
“Eu” = External microcomputer pull up
“Ed” = External microcomputer pull down
Det : Indicates judging state of input port. Level detection is “LV”; Edge detection is “Ed”; Detection by both shifting is “E&L”;
Serial data detection is “S” (Serial data output is also “S”).
Res : State at reset.
“H” = Outputs High Level at reset
“L” = Outputs Low Level at reset
“Z” = Becomes High impedance mode at reset
STBY : State of port when STANDBY mode.
“O/L” = Output port and “L”
“I” = Input port
Stop : State of port when Stop mode.
“O/L” = Output port and “L”
“I” = Input port
To Next Page
