AVR-5308CI / AVC-A1HD
56 P133 ACK SOMI I -
E↓&L
3V Ed Z I O/L
MAIN-SUB
μ
com comm. control pin
57 VSS VSS - -
-
-----GND
58 P132 REQ SIMO O C
-
3V Ed Z O/L O/L
MAIN-SUB
μ
com comm. control pin
59 VCC VCC2 - -
-
3V - - - - +3.3V
60 P131 RST SUB O C
-
3V Ed Z O/L O/L SUB-Éþcom reset output
61 P130 POWER/AC/TRIGGER RL O C
-
3V Ed Z O/L O/L
MAIN POWER/TRIGGER POWER relay control output (ON :
H)
62 P53 CLKOUT O C
-
3V - Z O/L O/L External memory access pin
63 P52/RD
RD OC
-
3V - Z O/L O/L External memory access pin
64 P51/BHE
BHE OC
-
3V - Z O/L O/L External memory access pin
65 P50/WRL
/WR/CE WR/FRASH CE O C
-
3V - Z O/L O/L External memory access pin
66 P127 E_RESET O C
-
3V Ed Z O/L O/L ETHERNET comm. control pin
67 P126 E SPI MIEO I -
E↓&L
3V Ed Z I O/L ETHERNET comm. control pin
68 P125 E SPI REQ I -
E↓&L
3V Ed Z I O/L ETHERNET comm. control pin
69 P47/CS0
/A23 CS0 OC
-
3V - Z O/L O/L External memory access pin
70 P46/CS1
/A22 CS1 OC
-
3V - Z O/L O/L External memory access pin
71 P45/CS2
/A21 CS2 OC
-
3V - Z O/L O/L External memory access pin
72 P44/CS3
/A20 CS3 OC
-
3V - Z O/L O/L External memory access pin
73 P43/A19 A19 O C
-
3V - Z O/L O/L External memory access pin
74 VCC VCC - -
-
3V - - - - +5V
75 P42 A18 O C
-
3V - Z O/L O/L External memory access pin
76 VSS VSS - -
-
3V - - - - GND
77 P41/A17 A17 O C
-
3V - Z O/L O/L External memory access pin
78 P40/A16 A16 O C
-
3V - Z O/L O/L External memory access pin
79 P37/D15 A15 O C
-
3V - Z O/L O/L External memory access pin
80 P36/D14 A14 O C
-
3V - Z O/L O/L External memory access pin
81 P35/D13 A13 O C
-
3V - Z O/L O/L External memory access pin
82 P34/D12 A12 O C
-
3V - Z O/L O/L External memory access pin
83 P33/A11 A11 O C
-
3V - Z O/L O/L External memory access pin
84 P32/D10 A10 O C
-
3V - Z O/L O/L External memory access pin
85 P31/D9 A9 O C
-
3V - Z O/L O/L External memory access pin
86 P124 MCPU TRANS RL O C
-
3V Ed Z O/L O/L
SUB TRANS Relay control pin (POWER ON : H) (ETHER=ON
or CEC ON (STANDBY : H))
87 P123/CTS6/RST6 ROM/RAM POWER O C
-
3V Ed Z O/L O/L 3.3V control pin for ROM/RAM,PLD
88 P122/RXD6 RXD MIXMO I -
-
3V - - I O/L XM RADIO control pin
89 P121/CLK6 RUSH RL O C
-
3V Ed Z O/L O/L Power relay for Rush prevention
90 P120/TXD6 TXD MOXMI O -
-
3V Eu Z O/L O/L XM RADIO control pin
91 VCC VCC - -
-
3V - - - - +5V
92 P30/A8 A8 O C
-
3V - Z O/L O/L External memory access pin
93 VSS VSS - -
-
-----GND
94 P27/AN27/A7 A7 O C
-
3V - Z O/L O/L External memory access pin
95 P26/AN26/A6 A6 O C
-
3V - Z O/L O/L External memory access pin
96 P25/AN25/A5 A5 O C
-
3V - Z O/L O/L External memory access pin
97 P24/AN24/A4 A4 O C
-
3V - Z O/L O/L External memory access pin
98 P23/AN23/A3 A3 O C
-
3V - Z O/L O/L External memory access pin
99 P22/AN22/A2 A2 O C
-
3V - Z O/L O/L External memory access pin
100 P21/AN21/A1 A1 O C
-
3V - Z O/L O/L External memory access pin
101 P20/AN20/A0 A0 O C
-
3V - Z O/L O/L External memory access pin
102 P17/INT5
/D15 D15 I/O C
-
3V - Z O/L O/L External memory access pin
103 P16/INT4
/D14 D14 I/O C
-
3V - Z O/L O/L External memory access pin
104 P15/INT3
/D13 D13 I/O C
-
3V - Z O/L O/L External memory access pin
105 P14/D12 D12 I/O C
-
3V - Z O/L O/L External memory access pin
106 P13/D11 D11 I/O C
-
3V - Z O/L O/L External memory access pin
107 P12/D10 D10 I/O C
-
3V - Z O/L O/L External memory access pin
108 P11/D9 D9 I/O C
-
3V - Z O/L O/L External memory access pin
109 P10/D8 D8 I/O C
-
3V - Z O/L O/L External memory access pin
110 P07/AN07/D7 D7 I/O C
-
3V - Z O/L O/L External memory access pin
111 P06/AN06/D6 D6 I/O C
-
3V - Z O/L O/L External memory access pin
112 P05/AN05/D5 D5 I/O C
-
3V - Z O/L O/L External memory access pin
113 P04/AN04/D4 D4 I/O C
-
3V - Z O/L O/L External memory access pin
114 P114 E POWER RL O C
-
3V Ed Z O/L O/L ETHERNET POWER ON/OFF switching (H : ON)
115 P113 SCPU POWER O C
-
3V Ed Z O/L O/L SUB CPU POWER ON/OFF switching (H : ON)
