External Power Amplifier
When using just one surround back speaker, connect it to the left
channel (SBL).
Power amplifier
USB Port
• In the initial status, USB memory devices can be used by connecting them to the USB port on the front panel.
• To change the port to be used, see “USB Select” on page 45.
• For instructions on playing the files on a USB memory device, see page 60, 61.
NOTE
• Set to the USB port you want to use.
• The AVC-A1HD is equipped with two USB ports, one each on the front and rear panels. It is not possible to use the set with USB memory
devices connected to both the ports at the same time. Select the USB port you want to use at the GUI menu “Source Select” – “NET/USB”
– “Playback Mode” – “USB Select” (vpage 45).
• Do not use the extension cable for connecting the USB memory deveice to the AVC-A1HD’s USB port.
Use of the extension cable may cause harmful interference.
n Front panel n Rear panel
USB memory device USB memory device
Connections
To Next Page
