16
AVR-1709/1609/1519/1509/689/589, AVC-1509
8. INPUT / CPU P.W.B ASSY
(1) Disconnect the FFC CABLE.（FFC ケーブルをはずす。）
(2) Disconnect the connector wires.（コネクタワイヤーをはずす。）
proceeding (手順): CABINET TOP → HDMI P.W.B ASSY → SIRIUS P.W.B ASSY
→ TUNER PACK → SPEAKER P.W.B ASSY
→ CHASSIS BACK SUB ASSY → VIDEO P.W.B ASSY
→ INPUT / CPU P.W.B ASSY
FFC CABLE
Picture C
CPU P.W.B ASSY
CP514
Picture B
INPUT P.W.B ASSY
CN704
Picture B
CN707
CN703CN702
INPUT P.W.B ASSY
CPU P.W.B ASSY
