Denon AVR-689 - Parts List of CPU PWB Unit Assy; Cpu P.w.b. Unit Assy

98
AVR-1709/1609/1519/1509/689/589, AVC-1509
CPU P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC804 963243001700D IC,CPU MICRO PROCESS M30626FHPFP
8952150900010
IC805 00D9630326906 IC LC72722PM-TLM-E AVR1709E2 J124727220010S
IC806 00D9600100301 IC KIA7812API J126781200040S
IC817 00D9630244907 IC SN74LV14APWR J040741400180S
IC818 00D9630367307 IC SN74AHCU04PWR J040740400290S
IC824 00D9630043807 IC BA4510F-E2/SOP8 J121451000010S *
IC827 00D9630043807 IC BA4510F-E2/SOP8
J121451000010S *
IC830 00D2622813903 SN74AHCT08PW-EL2 +C
J040740800190S
Q801 00D9630120704 TR KRA102S J520010200210S
Q802-805 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q806,807 00D9630121509 TR KTC3875S J522038750210S
Q808 00D9630148508 TRKTA1504S J520015040150S
Q809 00D9630120801 TR KRC102S J522010200210S
Q810D 00D9630245100 D,SWITCHING KDS226ST1(C3) K005022600020S
Q811D 00D9630245100 D,SWITCHING KDS226ST1(C3) K005022600020S
D802-804 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D805,806 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D807 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D807D 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D808D 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D809D 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D810D 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D811D 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
ZD801 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
RESISTORS GROUP
R857 00D9609003807 R,METAL FILM 100-J,1/4W
C060010163050S
CAPACITORS GROUP
C803 nsp C,CERAMIC 100PF-J/50V
D010101167160S
C804,805 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C806 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C807,808 nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C809 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C810 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C811,812 nsp C,CERAMIC 27PF-J/50V AVR1709E2 D010270167160S
C813 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C814-816 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C817 nsp C,CERAMIC 560PF-J/50V AVR1709E2 D010561167160S
C818 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C819 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C820 nsp C,CERAMIC 330PF-J/50V AVR1709E2 D010331167160S
C821 00D9630234205 C,ELECT 10UF-M/50V AVR1709E2 D040100087070S
C822 00D9639005862 C,ELECT 47UF-M/16V AVR1709E2 D040470083080S
C823 nsp C,CERAMIC 0.01UF-K/50V AVR1709E2 D010103777160S
C824,825 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C826-831 nsp C,CERAMIC 100PF-J/50V D010101167160S
C832,833 00D9630223009 R,THICK 0-J,1/16W AVR1709, 689EA C20000006M160S
C836,837 nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
ご注意：
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
