Denon AVR-887 Specifications

■
Assignable surround back (L/R) amplifiers for front (L/R) channel bi-amping,
or for Multi-zone playback
Amplifiers initially reserved for Surround back (L/R) channels can be assigned to
bi-wire Front (L/R) channels to improve playback quality in the front for enhanced
listening enjoyment. Or the amplifiers can be assigned to Zone 2 speakers.
■ 8ch EXT. IN terminal
■ Remote In/Out Ports
Other features
■
Audio Delay Function (0 - 200 msec.)
■
Personal Memory Plus, for Easy Operation
The AVR-887 includes the Personal Memory Plus function that automatically
remembers the surround mode you last used for each program source, so that you
do not need to select the mode again for that program.
■ Variable subwoofer crossover switching
(40/60/80/90/100/110/120/150/200/250Hz)
■
On Screen Display
■
5 Channel/ 7 Channel Stereo Mode
■ 3 User Mode Buttons
■ 2-line dot matrix display
■
Night Mode for not disturbing others
■
Function Rename
■
Input Function Level
■
REC OUT Selector
■
Front Panel Inputs (with S-Video, Digital Optical Input)
■
Front A/B Speaker Terminals
■ New user-friendly remote
■
High-grade 7 Channel Speaker Terminals (all ch)
■
Frequency Synthesis Tuning
• 56-Station AM/FM/XM Random Preset Memory Tuning
• Auto Preset Memory (AM/FM)
16700806 A
AVR-887
Input/Output Terminals For Every A/V System
Audio Inputs
9 sets of Analog Inputs
PHONO, CD, (TUNER), DVD/VDP, TV/DBS,
VCR-1, VCR-2, CDR/TAPE, V.AUX(FRONT)
8 Analog EXT. Inputs
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK L/R, SUBWOOFER
6 Digital Inputs
OPTICAL x 4 (incl. FRONT x 1)
COAXIAL x 2
Audio Outputs
1 set of Analog PRE OUT Terminals
7.1 ch
2 sets of Analog REC OUT Terminals
VCR, CDR/TAPE
1 Digital Output
OPTICAL x 1
Video Inputs
3 sets of Component Video Inputs
VIDEO1, VIDEO2, VIDEO3
5 Composite Inputs
DVD/VDP, TV/DBS, VCR-1, VCR-2, V.AUX(FRONT)
5 S-Video Inputs
DVD/VDP, TV/DBS, VCR-1, VCR-2, V.AUX(FRONT)
Video Outputs
1 set of Component Video Outputs
MONITOR
3 Composite Outputs
VCR-1, VCR-2, MONITOR
3 S-Video Outputs
VCR-1, VCR-2, MONITOR
Specifications
Power Amplifier Section
Rated output *THD figures are power amp stage values.
Front 100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
Center 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
135 W (6 ohms, 1 kHz, 0.7 % THD)
Surround 100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
Surround Back
100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
Preamplifier Section
Input sensitivity/Impedance
PHONO(MM) 2.5 mV/47 kohms
CD, DVD/VDP, TV/DBS, VCR-1, VCR-2, CDR/TAPE, V.AUX(FRONT)
200 mV/47 kohms
Output level/Load impedance
SUBWOOFER 1.2 V/10 kohms
CDR/TAPE, VCR-1, VCR-2 200 mV/47 kohms
Frequency response 10 Hz - 100 kHz (+1, -3 dB) (Tone Defeat On)
Signal-to-noise ratio 100 dB (IHF-A weighted) (Tone Defeat On)
Tone control Treble: ±6 dB at 10 kHz
Bass: ±6 dB at 100 Hz
FM Section
Tuning frequency range 87.5 - 107.9 MHz
Usable sensitivity 1.0 µV (11.2 dBf)
AM Section
Tuning frequency range 520 - 1710 kHz
Usable sensitivity 18 µV
General
Power supply AC 120 V, 60 Hz
Power consumption 5.5 A
Dimensions 17-3/32” (W) x 6-47/64” (H) x 16-27/64” (D)
434 (W) x 171 (H) x 417 (D) mm
Weight 29 lbs5oz
13.0 kg
*Design and specifications are subject to change without notice.
*”Dolby”, “Dolby Digital”, “Pro Logic II ”, “Dolby Digital EX” and the double-D device are registered trademarks of Dolby Laboratories Licensing Corporation.
*DTS is registered trademarks of DTS Technology.
*iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
*©2006 XM Satellite Radio Inc. All rights reserved.
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: 905-475-4085 ca.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: 201-762-6500 usa.denon.com
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
AVR887_E3.qxd 06.8.28 19:06 Page 2

Denon AVR-887 Specifications

Power

rated output front	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output front alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output center	100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output center alternative	135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround back	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround back alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
power supply	AC 120 V, 60 Hz
power consumption	5.5 A

Audio Inputs and Outputs

analog inputs	9 sets
analog ext inputs	8
digital inputs optical	4
digital inputs coaxial	2
audio delay function	0 - 200 msec.
variable subwoofer crossover	40/60/80/90/100/110/120/150/200/250 Hz

Video Inputs and Outputs

component video inputs	3 sets
composite inputs	5
s-video inputs	5
component video outputs	1 set
composite outputs	3
s-video outputs	3

Audio Performance

frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	100 dB (IHF-A weighted)
tone control treble	±6 dB at 10 kHz
tone control bass	±6 dB at 100 Hz

Weight and Dimensions

dimensions	17-3/32” (W) x 6-47/64” (H) x 16-27/64” (D)
dimensions metric	434 (W) x 171 (H) x 417 (D) mm
weight	29 lbs 5 oz
weight metric	13.0 kg
