Denon AVR-A1H User Manual

Setting items Detailed items Description Page
.
Inputs
Input Assign Changes input connector assignment. 216
Source Rename Changes the display name for input source. 218
Hide Sources Removes from the display input sources that are not used. 219
Source Level Adjusts the playback level of the audio input. 219
Input Select Sets the audio input mode. 220
.
Speakers
Audyssey
®
Setup
The acoustic characteristics of the connected speakers and listening room are
measured and the optimum settings are made automatically.
221
Manual Setup
Sets up the speakers manually or changes Audyssey
®
Setup settings.
232
.
Network
Information Displays network information. 255
Connection Selects whether to connect the home network to a wireless LAN or a wired LAN. 255
Settings Used for manually setting the IP address. 258
Network Control Enables network communication in standby power mode. 260
Friendly Name The “Friendly Name” is the name of this unit displayed on the network. You can change
the Friendly Name according to your preferences.
260
Diagnostics Used to check the network connection. 261
Contents Connections Playback Settings Tips Appendix
181
Front panel Display Rear panel Remote Index

Denon AVR-A1H Specifications

General

Channels	15.4
Power Output	150 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	7
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
Weight	70.5 lbs
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Wireless Audio	AirPlay 2, Bluetooth, HEOS
Phono Input	Yes
Frequency Response	10 Hz - 100 kHz
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Inputs	7 HDMI, 1 phono
Outputs	3 HDMI
Supported Audio Formats	MP3, WAV, FLAC, ALAC, DSD
Total Harmonic Distortion	0.05% (20 Hz - 20 kHz)
