Layout
Set the speaker layout when installing 1 set (2-channels) of Height, Ceiling or Dolby Atmos Enabled speakers.
The layouts that can be selected differ depending on the combinations of “Assign Mode” and “Floor” - “Layout” in the menu. (“ Assign
Mode ” (v p. 232), “Floor” - “ Layout ” (v p. 235))
Settings AUDIO OUT connectors
Height Sp Dolby Sp Layout HEIGHT 1 HEIGHT 2 HEIGHT 3
HEIGHT 4/FRONT
WIDE
None None - - - - -
2ch None
Front Height Front Height - - -
Top Front Top Front - - -
Top Middle Top Middle - - -
Top Rear Top Rear - - -
Rear Height Rear Height - - -
None 2ch
Front Dolby Front Dolby - - -
Surround Dolby Surround Dolby - - -
Back Dolby z
Back Dolby - - -
z This can be selected when using Surround Back speakers. Set “Floor” - “Layout” in the menu to “5ch & SB” or “5ch & SB & FW”. (v p. 235)
