Example connection when using two sets of height speakers and one set of front wide speakers
.
C
FL FR
SW
RSLS
FHL FHR
RHL RHR
FWL FWR
SBL
SBR
0
Set “Floor” - “Layout” to “5ch & SB & FW” and “Height Sp” to “4ch” in the menu
when connecting in this configuration. (v p. 235)
.
