The combination of the HEIGHT1, HEIGHT2, HEIGHT3 and HEIGHT4 channels can be changed to the following patterns according to the speaker
system being used.
Set this from “Amp Assign” in the menu. (v p. 232)
Combinations of height speakers to be used
Connected speaker terminals
Number of
height / ceiling
speakers
Number of
Dolby
Speakers
Combination pattern HEIGHT 1 HEIGHT 2 HEIGHT 3
HEIGHT 4/
FRONT
WIDEz1
2ch
2ch None
Front Height Front Height - - -
Top Front Top Front - - -
Top Middle Top Middle - - -
Top Rear Top Rear - - -
Rear Height Rear Height - - -
None 2ch
Front Dolby Front Dolby - - -
Surround Dolby Surround Dolby - - -
Back Dolbyz2
Back Dolby - - -
Contents Connections Playback Settings Tips Appendix
69
Front panel Display Rear panel Remote Index

Denon AVR-A1H Specifications

General

Channels	15.4
Power Output	150 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	7
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
Weight	70.5 lbs
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Wireless Audio	AirPlay 2, Bluetooth, HEOS
Phono Input	Yes
Frequency Response	10 Hz - 100 kHz
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Inputs	7 HDMI, 1 phono
Outputs	3 HDMI
Supported Audio Formats	MP3, WAV, FLAC, ALAC, DSD
Total Harmonic Distortion	0.05% (20 Hz - 20 kHz)
