Combinations of height speakers to be used
Connected speaker terminals
Number of
height / ceiling
speakers
Number of
Dolby
Speakers
Combination pattern HEIGHT 1 HEIGHT 2 HEIGHT 3
HEIGHT 4/
FRONT
WIDEz1
4ch
2ch 2ch
Front Dolby & Top Rear Front Dolby Top Rear - -
Front Dolby & Rear Height Front Dolby Rear Height - -
Front Height & Surr. Dolby Front Height Surround Dolby - -
Front Height & Back Dolbyz2
Front Height Back Dolby - -
Top Front & Surr. Dolby Top Front Surround Dolby - -
Top Front & Back Dolbyz2
Top Front Back Dolby - -
4ch None
Front Height & Top Middle Front Height Top Middle - -
Front Height & Top Rear Front Height Top Rear - -
Front Height & Rear Heightz3
Front Height Rear Height - -
Front Height & Surr. Height Front Height Surr. Height - -
Top Front & Top Rear Top Front Top Rear - -
Top Front & Rear Height Top Front Rear Height - -
Top Middle & Rear Height Top Middle Rear Height - -
None 4ch
Front Dolby & Surr. Dolby Front Dolby Surround Dolby - -
Front Dolby & Back Dolbyz2
Front Dolby Back Dolby - -
