Denon AVR-S510BT Service Manual

22
3. ChangeVideoFormatandDisplayLanguageMode
3.1. Operations
Hold down buttons below for at least 3 seconds while the power is on.
"PRESET -", "PRESET +", "TUNE -" (AVR-S510BT)
"TUNE -", "TUNE +", "DIMMER" (AVR-X520BT / X518CI)
f
Note: Do not start in this mode when displaying the OSD MENU using the MENU button.
3.2. Actions
This unit is in VIDEO Format at startup.
Press the button below to switch between Video Format and Display Language.
"TUNE +" AVR-S510BT
"STATUS" AVR-X520BT / X518CI
f
3.2.1.VideoFormat
Press the button below to switch between NTSC and PAL.
"PRESET +" or "TUNE -" AVR-S510BT
"PRESET +" or "DIMMER" AVR-X520BT / X518CI
f
FLD
V . F o r m a t : < N T S C >
↓↑
FLD
V . F o r m a t : < P A L >
↓↑
Return to top.
Press the "Preset -" button to set format. The display then return to the normal mode.
3.2.1.Language
Press the button below to switch display language.
"PRESET +" or "TUNE -" AVR-S510BT
"PRESET +" or "DIMMER" AVR-X520BT / X518CI
f
FLD
L a n g . : < E N G L I S H >
↓↑
FLD
L a n g . : < S P A N I S H >
↓↑
FLD
L a n g . : < F R E N C H >
↓↑
FLD
L a n g . : < C H I N E S E >
↓↑
Return to top.
Press the "Preset -" button to set display language. The display then return to the normal mode.

Denon AVR-S510BT Specifications

General

Channels	5.2
Power Output	70 Watts per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Response Bandwidth	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
HDMI Inputs	5
HDMI Outputs	1
HDMI Pass-Through	Yes
HDMI Version	2.0
HDCP Version	2.2
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audio Decoding	Dolby TrueHD, DTS-HD Master Audio
Wi-Fi	No
Inputs	5 HDMI, 2 digital optical, 2 analog
Outputs	1 HDMI
Dimensions	17.1 in x 12.6 in x 5.9 in
Amplifier Output Details	5 channels
