Denon AVR-S510BT Service Manual

Magnify schematic / printed circuit board
diagrams - 2
(Pan & Zoom function)
ThePan&Zoomfunctionletsyouseewhichpartof
amagnieddiagramisbeingshowninaseparate
window.
[Example using Adobe Reader X]
Onthe"View"menu,pointto"Zoom",andthenclick
"Pan & Zoom".
• ThePan&Zoomwindowappearsonthescreen.
[Example using Adobe Reader 9]
Onthe"Tools"menu,pointto "Select & Zoom",and
thenclick"Pan & Zoom Window".
Magnify schematic / printed circuit board
diagrams - 3
(Loupe Tool function)
TheLoupeToolfunctionletsyoumagnifyaspecic
partofadiagraminaseparatewindow.
[ExampleusingAdobeReaderX]
Onthe"View"menu,pointto"Zoom",andthenclick
"Loupe Tool".
• TheLoupeToolwindowappearsonthescreen.
[Example using Adobe Reader 9]
Onthe"Tools"menu,pointto"Select & Zoom",and
thenclick"Loupe Tool Window".
5

Denon AVR-S510BT Specifications

General

Channels	5.2
Power Output	70 Watts per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Response Bandwidth	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
HDMI Inputs	5
HDMI Outputs	1
HDMI Pass-Through	Yes
HDMI Version	2.0
HDCP Version	2.2
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audio Decoding	Dolby TrueHD, DTS-HD Master Audio
Wi-Fi	No
Inputs	5 HDMI, 2 digital optical, 2 analog
Outputs	1 HDMI
Dimensions	17.1 in x 12.6 in x 5.9 in
Amplifier Output Details	5 channels
