Paths to be conrmed Display Settings What to conrm
4 HDMI
g.04a
g.04b
A05:HDMI
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : Surround Back
MAIN ZONE : On
ZONE2 : Off
・ HDMI input ⇒ Speaker output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
5
Analog AD
(MAIN)
g.05a
g.05b
A06:AD
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Vol 60.0
Amp assign : Surround Back
Speaker Cong ALL Speaker = Small / SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Analog input ⇒ Pre OUT output (Subwoofer)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20dB when Relative
settings are used)
6
Analog Amp Assign
(Amp Assign :
ZONE2)
g.06
A07:ASSIGN-Z2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Vol 60.0
Amp assign : ZONE2
MAIN ZONE : On
ZONE2 : On
・ Analog input ⇒ Speaker output (ZONE2 L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20dB when Relative
settings are used)
1.6. Conrmation items for the video system
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1 Analog Video pass g.07
V01:VIDEO PASS
Input Source : CBL/SAT
MAIN ZONE : On
・ CVBS input ⇒ CVBS output
(
b
The input source can be switched to any source except CBL/SAT.)
2 HDMI pass g.08
V03:HDMI PASS
Input Source : CBL/SAT
MAIN ZONE : On
・ HDMI input (MAIN function) ⇒ HDMI output (MAIN)
(
b
The input source can be switched to any source except CBL/SAT.)
3 HDMI CEC g.09
V04:HDMI CEC
Input Source : CBL/SAT
HDMI Control : On
MAIN ZONE : On
・ When the power supply of a TV is put in the standby mode, make sure that the power supply
of this unit is also put in the standby mode.
(
b
The input source can be switched to any source except CBL/SAT.)
・ The ARC path can also be checked (check this using the TV input source).
4
HDMI Audio
(Audio : AVR)
g.04a
g.04b
V05:H.AUDIO-AVR
Input Source : CBL/SAT
HDMI Control : Off
HDMI Audio : AVR (if checking the audio output from
AVR)
・ HDMI input (PCM , DolbyDigital , DTS) ⇒ Speaker output.
・ HDMI input(HD audio) ⇒ Speaker output.
(
b
The input source can be switched to any source except CBL/SAT.)
5
HDMI Audio
(Audio : TV)
g.10
V06:H.AUDIO-TV
HDMI Audio : TV (if checking the audio from TV) ・ HDMI input (PCM, DolbyDigital , DTS) ⇒ HDMI output (audio output from connected TV)
(
b
The input source can be switched to any source except CBL/SAT.)
6 GUI g.11
V07:GUI MENU ON
Input Source : CBL/SAT
Setup Menu : On
MAIN ZONE : On
・GUI display ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
111
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon avr-s720w Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-Through	Yes
HDR Support	Yes
3D Pass-Through	Yes
HDMI Version	2.0a
HDCP Version	2.2
AirPlay	Yes
Built-in HEOS	No
Phono Input	No
Ethernet Port	Yes
Dimensions (W x H x D)	17.1 x 6.6 x 13.3 inches
Power Output per Channel	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
USB Port	Yes
