Denon avr-s720w Service Manual

DIGITAL
DIGITAL PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded view
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D7131 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1 1
D7401 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7402 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7403 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7404 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7502 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7702 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7703 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7704 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D7705 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D8051 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D8201 943202501200S DIODE,ZENER,1/2W,7.5V CVDZJ7V5BL 1 *
D8202 943202501200S DIODE,ZENER,1/2W,7.5V CVDZJ7V5BL 1 *
D8203 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D8204 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D8205 943202501210S DIODE,ZENER(3.6V/0.5W,SOD-123) CVDMM1Z523V6B 1 *
D8206 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D8501 943202501220S DIODE, ZENER(6.8V/0.5W, SOD-123) E3 CVDMM1Z526V8B 1 *
D8502 943202501220S DIODE, ZENER(6.8V/0.5W, SOD-123) E3 CVDMM1Z526V8B 1 *
D8801 943202501230S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z525V1B 1 *
D8802 943202501230S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z525V1B 1 *
IC701 943236101940S I.C,HDMI2.0Transceiver(HQFP-144P) CVIMN864788A 1
IC721 23681050460AS I.C,HDMI2.0Transceiver(HQFP-144P) CVIMN864788 1
IC731 943236012460S I.C,HDMITransceiver(LQFP-144P) CVIADV7623BSTZ 1
IC732 943248103710S
I.C,OSDSerialFlash(E3)MX25L3206EM2I-12G
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
S720, E3 VVIANAM2317AV 1 *
IC732 943248103720S
I.C , OSD Serial Flash (E1C)MX25L3206EM2I-12G
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
E1C VVIANAM2320AV 1 *
IC732 943248103730S
I.C , OSD Serial Flash (K)MX25L3206EM2I-12G
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
JP VVIANAM2319AV 1 *
IC732 943248103740S
I.C , OSD Serial Flash (E2)MX25L6406EM2I-12G
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
E2 VVIANAM2318AV 1 *
IC733 943239101510S I.C,MUX/DEMUX(TSSOP-16P) CVISN74CBT3251PWR 1
IC741 943239101860S I.C,DC-DCCONVERTER(SOT-23) CVITPS563200DDCR 1 *
IC742 943239101860S I.C,DC-DCCONVERTER(SOT-23) CVITPS563200DDCR 1 *
IC743 943239101860S I.C,DC-DCCONVERTER(SOT-23) CVITPS563200DDCR 1 *
IC744 943239101860S I.C,DC-DCCONVERTER(SOT-23) CVITPS563200DDCR 1 *
IC745 943239101860S I.C,DC-DCCONVERTER(SOT-23) CVITPS563200DDCR 1 *
IC747 943239101860S I.C,DC-DCCONVERTER(SOT-23) CVITPS563200DDCR 1 *
IC749 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC751 943243103310S
I.C,MAINMCU(E3)R5F56108VNFP
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
S720, E3 VVIANAM2310AV 1 *
IC751 943243103320S
I.C , MAIN MCU(E2)R5F56108VNFP
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
E2 VVIANAM2312AV 1 *
IC751 943243103330S
I.C , MAIN MCU(E1C)R5F56108VNFP
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
E1C VVIANAM2314AV 1 *
IC751 943243103340S
I.C , MAIN MCU(K)R5F56108VNFP
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
JP VVIANAM2313AV 1 *
IC752 943239101500S I.C,EEPROM(128KBIT,SOP-8P) CVIR1EX24128BSAS0I 1
IC753 943233102030S I.C,Shift/StoreRegister(SOIC-16P) CVIMC74HC4094ADR2G 1
IC761 963239002150S I.C,OCTALBUFFER/DRIVER CVISN74LVC244APWR 1
IC771 00D2623077900 I.C,HEXINVERTER S720, E3 HVITC74VHCU04FT 1
IC772 943236101350D I.C,DIR/DIT(WITHADC,LQFP-48P) CVIPCM9211PTR 1
IC773 943248103750S
I.C,PLD(AVRS720W/AVRX1300W)5M80ZT100C5N
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
VVIANAM2316AV 1 *
IC781 963245100680S I.C,AUDIODSP(QUAD-CORE,LQFP-144P) CVICS49844A-CQZ 1
IC782 943248103760S
I.C,DSPSerialFlash(AVRS720W/AVRX1300W)MX25L6406EM2I-12G
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
VVIANAM2315AV 1 *
IC783 963239002150S I.C,OCTALBUFFER/DRIVER CVISN74LVC244APWR 1
IC784 943246101180S I.C,SDRAM64M(TSOPII-54P) CVIM12L64164A-5TG2Y 1
IC791 943239101080S I.C,DAC(8CH,HTSSOP-48) CVIPCM1690DCAR 1
IC792 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC793 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC794 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC795 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC801 943239101090S I.C,Highsideswitch(TSSOP-B8) CVIBD82065FVJ-E2 1
IC802 23671011050AS I.C,IPODAUTHENTICATIONFROMD&M CVI23671011050AS_DM 1
IC803 24681009260AS
I.C,SERIALFLASH(256M,SOP-16)MX25L25635FMI-10G
See PROCEDURE AFTER REPLACING THE U-COM, ETC
.
CVIMX25L25635FMI-10G 1
IC804 943239101520S I.C,0-BITBUFFER/DRIVERTSSOP24TEXASINSTRUMENTS CVISN74LVC827APWR 1
IC805 943239100690S I.C,2CHDAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC806 943231102150S IC,regulator(3.3V,SSOP5) CVIBU33TD3WG 1
IC821 943235100520S I.C,INPUTWITH8CHVOLUME(52PLQFP) CVINJU72340AFH3 1
IC851 90M-HC109850R I.C , VIDEO 2CH E3 CVIBD3812F 1
IC852 943232100380S I.C , DUAL OPAMP(SOP-8P) E3 CVINJM8080G 1
IC881 90M-HC109700R I.C,VIDEOS/W(JRC) CVINJM2595MTE1 1
Q7101 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7102 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7111 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7112 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7121 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7122 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7201 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7202 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7211 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7212 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7401 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7402 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7403 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7404 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7405 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7406 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7407 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7408 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7409 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7410 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7411 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q7412 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7413 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7414 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7415 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7416 00D2757001907 MOSFET(P-CH,2.5VPOWERTRENCH) CVTFDC608PZ 1
Q7417 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7418 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7419 943214500020S T.R,2SC3052 CVT2SC3052 1
Q7420 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7421 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q7422 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q7423 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
13

Denon avr-s720w Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-Through	Yes
HDR Support	Yes
3D Pass-Through	Yes
HDMI Version	2.0a
HDCP Version	2.2
AirPlay	Yes
Built-in HEOS	No
Phono Input	No
Ethernet Port	Yes
Dimensions (W x H x D)	17.1 x 6.6 x 13.3 inches
Power Output per Channel	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
USB Port	Yes
