Denon avr-s720w Service Manual

ZONE2
LINE IN 0dB
(200m V)
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
AVRS720W /X1300W LEVEL DIAG RAM
LINE IN
H/P O U T
SPK OU T
NJU72340A
FRO NT
ZO NE2
BD3812F
-50dB
0dB ( 200mV rm s )
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
-50dB
+30dB
+29dB
4.27Vrm s/ 8ohm
277m Vrm s/33ohm
SPK OU T
G A IN
ADJ.
PREOU T 150m Vrm s
H/P O U T
PO W ERA M P GAIN
ZO N E 2 SEL .
REC INH.
ANALO G
NJU72340 M AX.O U T P U T 3 . 8 V rm s
NJM 8080 M AX.O UTPUT 7.78V r m s
-18dB
+15dB
NO T U S E
ZO NE2 O UT
33
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon avr-s720w Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-Through	Yes
HDR Support	Yes
3D Pass-Through	Yes
HDMI Version	2.0a
HDCP Version	2.2
AirPlay	Yes
Built-in HEOS	No
Phono Input	No
Ethernet Port	Yes
Dimensions (W x H x D)	17.1 x 6.6 x 13.3 inches
Power Output per Channel	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
USB Port	Yes
