PCM1690DCAR (DIGITAL_MAIN DAC : IC791)
PCM1690 Pin Function
TERMINAL
I/O
PULL-
DOWN
5-V
TOLERANT
DESCRIPTION
NAME PIN
RSV2 1 Reserved, tied to analog ground
RSV1 2 Reserved, left open
RSV2 3 Reserved, tied to analog ground
RSV1 4 Reserved, left open
RSV2 5 Reserved, tied to analog ground
LRCK 6 I Ye s No Audio data word clock input
BCK 7 I Yes No Audio data bit clock input
DIN1 8 I No No Audio data input for DAC1 and DAC2
DIN2 9 I No No Audio data input for DAC3 and DAC4
DIN3 10 I No No Audio data input for DAC5 and DAC6
DIN4 11 I No No Audio data input for DAC7 and DAC8
VDD 12 Digital power supply, +3.3 V
DGND 13 Digital ground
SCKI 14 I No Yes System clock input
RST 15 I Yes Yes Reset and power-down control input with active low
ZERO1 16 O No No Zero detect ag output 1
ZERO2 17 O No No Zero detect ag output 2
AMUTEI 18 I No Yes Analog mute control input with active low
AMUTEO 19 O No Yes Analog mute status output(1) with active low
MD/SDA/DEMP 20 I/O No Yes
Input data for SPI, data for I2C(1), de-emphasis con-
trol for hardware control mode
MC/SCL/FMT 21 I No Yes
Clock for SPI, clock for I2C, format select for hard-
ware control mode
MS/ADR0/RSV 22 I Yes Yes
Chip Select for SPI, address select 0 for I2C, reserve
(set low) for hardware control mode
TEST/ADR1/RSV 23 I/O No Yes
Test (factory use, left open) for SPI, address select 1
for I2C, reserve (set low) for hardware control mode
MODE 24 I No No
Control port mode selection. Tied to VDD: SPI, left
open: H/W mode, tied to DGND: I2C
VCC1 25 Analog power supply 1, +5 V
VCOM 26 Voltage common decoupling
AGND1 27 Analog ground 1
RSV2 28 Reserved, tied to analog ground
PIN CONFIGURATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
RSV2
VCC2
AGND2
RSV2
VOUT1
VOUT1+
VOUT2
VOUT2+
VOUT3
VOUT3+
VOUT4
VOUT4+
VOUT5
VOUT5+
VOUT6
VOUT6+
VOUT7
VOUT7+
VOUT8
VOUT8+
RSV2
AGND1
VCOM
VCC1
RSV2
RSV1
RSV2
RSV1
RSV2
LRCK
BCK
DIN1
DIN2
DIN3
DIN4
VDD
DGND
SCKI
RST
ZERO1
ZERO2
AMUTEI
AMUTEO
MD/SDA/DEMP
MC/SCL/FMT
MS/ADR0/RSV
TEST/ADR1/RSV
MODE
PCM1690
ThermalPad
PCM1690
SBAS448A OCTOBER 2008 REVISED JANUARY 2009..............................................................................................................................................
www.ti.com
DCA PACKAGE
HTSSOP-48 (12 mm x 8 mm)
(TOP VIEW)
TERMINAL FUNCTIONS
TERMINAL
PULL- 5-V
NAME PIN I/O DOWN TOLERANT DESCRIPTION
RSV2 1 Reserved, tied to analog ground
RSV1 2 Reserved, left open
RSV2 3 Reserved, tied to analog ground
RSV1 4 Reserved, left open
RSV2 5 Reserved, tied to analog ground
LRCK 6 I Yes No Audio data word clock input
BCK 7 I Yes No Audio data bit clock input
DIN1 8 I No No Audio data input for DAC1 and DAC2
DIN2 9 I No No Audio data input for DAC3 and DAC4
DIN3 10 I No No Audio data input for DAC5 and DAC6
DIN4 11 I No No Audio data input for DAC7 and DAC8
6 Submit Documentation Feedback
Copyright © 20082009, Texas Instruments Incorporated
Product Folder Link(s): PCM1690
TERMINAL
I/O
PULL-
DOWN
5-V
TOLERANT
DESCRIPTION
NAME PIN
VOUT8+ 29 O No No Positive analog output from DAC8
VOUT8- 30 O No No Negative analog output from DAC8
VOUT7+ 31 O No No Positive analog output from DAC7
VOUT7- 32 O No No Negative analog output from DAC7
VOUT6+ 33 O No No Positive analog output from DAC6
VOUT6- 34 O No No Negative analog output from DAC6
VOUT5+ 35 O No No Positive analog output from DAC5
VOUT5- 36 O No No Negative analog output from DAC5
VOUT4+ 37 O No No Positive analog output from DAC4
VOUT4- 38 O No No Negative analog output from DAC4
VOUT3+ 39 O No No Positive analog output from DAC3
VOUT3- 40 O No No Negative analog output from DAC3
VOUT2+ 41 O No No Positive analog output from DAC2
VOUT2- 42 O No No Negative analog output from DAC2
VOUT1+ 43 O No No Positive analog output from DAC1
VOUT1- 44 O No No Negative analog output from DAC1
RSV2 45 Reserved, tied to analog ground
AGND2 46 Analog ground 2
VCC2 47 Analog power supply 2, +5 V
RSV2 48 Reserved, tied to analog ground
(1) Open-drain conguration in out mode.
49
