Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” (v p. 190) settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone
playback.
Perform “Amp Assign” (v p. 190) settings to suit the number of rooms and speaker configuration to be installed.
Playback speaker and zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel Not used ZONE2 (Default) 33
7.1-channel (surround back) Not used Surround Back 34
7.1-channel (front height) Not used Front Height 35
7.1-channel (front wide) Not used Front Wide 36
5.1-channel (bi-amp connection for front speaker) Not used Bi-Amp 37
5.1-channel + front speaker of second unit Not used Front B 38
5.1-channel 2-channel ZONE2 (Default) 39
The sound mode that can be selected varies according to the speaker configuration. See “Relationship between sound modes and channel output” (v p. 248) for the sound
modes that are supported.
Contents Connections Playback Settings Tips Appendix
32
Front panel Display Rear panel Remote Index
