F
NETWORK connector
Used to connect to a LAN cable when connecting to a wired LAN
network. (v
p. 93)
G
AC inlet (AC IN)
Used to connect the power cord. (v p. 97)
H
FM/AM antenna terminals (ANTENNA)
Used to connect FM antennas and AM loop antennas. (v
p. 91)
I
TRIGGER OUT jacks
Used to connect devices equipped with the trigger function.
(v
p. 96)
J
REMOTE CONTROL jacks
Used to connect infrared receivers/transmitters in order to operate this
unit and external devices from a different room. (v
p. 95)
K
RS-232C connector
Used to connect home automation controller devices fitted with
RS-232C connectors. Consult the owner’s manual of the home
automation controller for more information about serial control of this
unit.
Perform the operation below beforehand.
A
Turn on the power of this unit.
B
Turn off the power of this unit from the external controller.
C
Check that the unit is in the standby mode.
