Denon AVR-X6200W - Page 50

n
Example connections when using front wide speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with front wide speakers.
.
FL
SW
C
SL
FR
SR
FWL FWR
.
CENTER SURROUND SURROUNDFRONT FRONT WIDE/HEIGHT2FRONT WIDE/HEIGHT2 FRONT
HEIGHT1 HEIGHT1 SURROUND BACKSURROUND BACK
SW FR FL C SR SL
FWR FWL
0
Set “Floor” - “Layout” to “5ch & FW” in the menu when connecting in this configuration. (v p. 246)
