Example connections when using height speakers
.
FL
SW
C
SL
FR
SR
FHL FHR
.
CENTER SURROUND SURROUNDFRONT HEIGHT1 HEIGHT1FRONT FRONT WIDE/HEIGHT2FRONT WIDE/HEIGHT2
SURROUND BACKSURROUND BACK
SW FR FL C SR SL
FHR FHL
0
Set “Floor” - “Layout” to “5ch” and “Height Sp” to “2ch” in the menu when connecting in this configuration. (v p. 246)
0
The rear height speakers can be connected instead of the front height speakers. In this case, set the height speakers to be connected under “Height” - “Layout” in the menu.
(v p. 247)
