Denon AVR-X6300H Service Manual

3-4.1. Actions
This mode enables the unit to display the accumulated operating time, power On count and each pro-
tection count.
3-4.2. Starting up
While holding down buttons "
ZONE3 SOURCE
" and "
STATUS
" simultaneously, press the power button
to turn on the power.
Select the "
4. OP INFO
" using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to conrm.
3-4.3. Operations
Press the "
STATUS
" button after starting up this device in Operation Info mode.
The following information is displayed in the following order.
(a) Accumulated operating time
L1
Operation Time
L2
Total: ______H
↑ Time display
"
STATUS
"
(b) Power On count
L1
Power On Time
L2
Total: ______H
↑ Count display
"
STATUS
"
(c) DC / ASO Protection count
L1
Protection Time
L2
DC:___/ASO:___
"
STATUS
"
(d) Thermal Protection (E) count
L1
Protection Time
L2
THM E:___/F:___
"
STATUS
"
(e) Current Protection count
L1
Protection Time
L2
Current:___
"
STATUS
"
(Returns to normal display)
3-4. Operation Info Mode
135
Caution in
servicing
Electrical Mechanical Repair Information Updating
