10) Press "MENU" button and conrm that GUI is displayed on the TV screen. Use the cursor key to select
"Speakers>Manual Setup>Amp Assign" and set "Assign Mode" to "11.1ch". and set "-Height Sp" to
"4ch".
11) Press "MENU" button and conrm that GUI is displayed on the TV screen. Use the cursor key to select
"Speakers>Manual Setup>Speaker Cong" and set "Subwoofer" to "2spkers".
12) Set the BD disc to the DBT-3313UD.
13) Turn "SOURCE SELECT" knob, and set Source to "AUX1". Play the track with DTS-HD fs=96 kHz/7.1
ch sound recorded in it with the DBT-3313UD, and press "Music" button on the remote, and select
"Multi Ch Stereo".
After that, conrm below.
(A) The video is output on TV.
(B) The sound is output from all the terminals when FR, FL, C, SR, SL, SBR, SBL, Hight1R, Hight1L,
Hight2R, and Hight2L of the PREOUT output (RCA terminal) are connected to the Pre-main Ampli-
er.
(C) The sound is output from all the terminals when the subwoofer is connected to "SW1 and SW2".
(D) Denon Link HD indicator on BD Player lights up.
14) Set the BD disc to the BD Player.
15) Set the BD Player resolution to 720p or over.
16) Turn "SOURCE SELECT" knob, and set Source to "AUX1". Play the track with DTS-HD fs=96 kHz/7.1 ch
sound recorded in it with the BD Player, and press "Music" button on the remote, and select "Multi
Ch Stereo".
After that, conrm below.
(A) The video is output on TV.
(B) The sound is output from all the terminals when FR, FL, C, SR, SL, SBR, SBL, Hight1R, Hight1L,
Hight2R, and Hight2L of the PREOUT output (RCA terminal) are connected to the Pre-main Ampli-
er.
(C) The sound is output from all the terminals when the subwoofer is connected to "SW1 and SW2".
17) Turn "SOURCE SELECT" knob, and set Source to "DVD". Play the BD Player, and press "Music" button
on the remote, and select "Multi Ch Stereo".
After that, conrm below.
(A) The video is output on TV.
(B) The sound is output from all the speaker terminals.
18) Change the disc for BD Player to CD Disc, and Turn "SOURCE SELECT" knob, and set Source to "CD".
Play the BD Player, and press "Music" button on the remote, and select "Stereo".
Tune Zone2 and Zone3 ON.
After that, conrm below.
(A) The sound is output from FL and FR speaker terminals.
After conrmation, connect speakers to FL and FR speaker terminals.
(B) The sound is output from all the terminals when Zone2R, Zone2L, Zone3R, and Zone3L of the
PREOUT output (RCA terminal) are connected to the Pre-main Amplier.
19) Via HEOS App, Operate HEOS speaker to start playing CD input source of the AVR.
After that, conrm below.
(A) The music that playing by BD Player can be played on HEOS speaker.
20) Turn "SOURCE SELECT" knob, and set Source to "TUNER (FM)". Conrm that the FM radio can be
heard (only for models that are equipped with a TUNER).
21) Turn "SOURCE SELECT" knob, and set Source to "Online Music". Connect to the Network and conrm
below.
(A) The music in the DLNA server can be played.
(B) The music in the USB memory device can be played.
22) Connect Bluetooth music player and conrm below.
(A) The music in the Bluetooth music player device can be played.
23) After turning the power OFF with "POWER ON/OFF" button, press "POWER ON/OFF" button while
simultaneously pressing "STANDARD" and "HOME THX CINEMA" buttons to turn the power ON. After
conrming that FL tube starts ushing at intervals of about 1 second, release the two buttons. Then,
press "POWER ON/OFF" button to turn the power OFF.
