Settings AUDIO OUT connectors
Height Sp Dolby Sp NOTE Layout HEIGHT 1 HEIGHT 2
2ch 2ch
z 1
Front Dolby & Top Rear Front Dolby Top Rear
Front Dolby & Rear Height Front Dolby Rear Height
Front Height & Surr. Dolby Front Height Surround Dolby
Front Height & Back Dolby z 4
Front Height Back Dolby
Top Front & Surr. Dolby Top Front Surround Dolby
Top Front & Back Dolby z 4
Top Front Back Dolby
None 4ch
z 1
Front Dolby & Surr. Dolby Front Dolby Surround Dolby
Front Dolby & Back Dolby z 4
Front Dolby Back Dolby
z1
This can be selected when “Assign Mode” is set to “11.1ch” or “9.1ch” in the menu.
z4
This can be selected when “Assign Mode” is set to “11.1ch” and “Floor” - “Layout” is set to “5ch & SB” in the menu.
Settings AUDIO OUT connectors
Height Sp Dolby Sp NOTE Layout Top Surr. Out HEIGHT1 HEIGHT2 SUBWOOFER2
SURROUND
BACK L
5ch None
z
5
Front Height & Surr. Height
SUBWOOFER 2
Front Height
Surround
Height
Top Surround -
SURR. BACK L - Top Surround
Front Height & Rear Height z 2
SUBWOOFER 2
Front Height Rear Height
Top Surround -
SURR. BACK L - Top Surround
z
2
For the best Auro-3D experience Surround Height speakers are recommended, however you may substitute Rear Height speakers from a Dolby Atmos speaker setup
in place of Surround Height speakers.
z5
This can be selected when “Assign Mode” is set to “11.1ch” in the menu.
