Digital audio connectors (DIGITAL AUDIO)
Used to connect devices equipped with digital audio connectors.
0
“Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel)” (v p. 76)
0
“Connection 3 : TV equipped without an HDMI
connector” (v p. 77)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v
p. 79)
0
“Connecting a DVD player or Blu-ray Disc player” (v p. 80)
M
Speaker terminals (SPEAKERS)
Used to connect speakers. (v
p. 40)
N
PRE OUT connectors
Used to connect a subwoofer with built-in amplifier or an external power
amplifier.
0
“Connecting the subwoofer” (v
p. 41)
0
“Connecting ZONE” (v p. 165)
O
Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
0
“Connection 3 : TV equipped without an HDMI
connector” (v
p. 77)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v
p. 79)
0
“Connecting a DVD player or Blu-ray Disc player” (v p. 80)
P
Component video connectors (COMPONENT VIDEO)
Used to connect devices equipped with component video connectors.
0
“Connection 3 : TV equipped without an HDMI
connector” (v
p. 77)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 79)
0
“Connecting a DVD player or Blu-ray Disc player” (v
p. 80)
NOTE
0
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
