o
Example connection when using two sets of Dolby Atmos Enabled speakers
.
C
SW
SL SR
FL
FR
FDL FDR
SDL SDR
0
Set “Floor” - “Layout” to “5ch” or set “5ch & SB” and “Dolby Sp” to “4ch” in the
menu when connecting in this configuration. (v
p. 223, 224)
.
ASSIGNABLE ASSIGNABLE
SPEAKERS
CENTER SURROUND SURROUNDFRONTFRONT
SURROUNDBACKSURROUNDBACK
SDR SDLFDR FDL
HEIGHT 1
z
HEIGHT 2
z
SW
FR FL C SR SL
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v
p. 58)
Contents
Connections Playback Settings Tips Appendix
56
Front panel Display Rear panel Remote Index
