@ When there are no tracks that can be picked in.the blank portion of side
A {side B), cancel the last track of side A (side B), increase the blank
portion, and pick an available track in the new blank portion.
At this time the tracks cancelled from side A are automatically fixed on
side B.
When there are no tracks that can be picked even though the last track
of side A (side B) has been cancelled, the setting will remain the same
even if the cancellation is suspended.
Example of tracks not being placed in the blank spaces
[i [2 ]sfe|Lats | 6 |
Side 8
When tracks are not placed in blank spaces as shown in Side A
the diagram to the right, the last track (track 3 in the
example) is cancelled and substituted with a track from
side B. :
(3) Link Function (LINK)
The link function provides the convenience of editing a number of discs in
succession.
The tink operation is used following the tape time specification of the time
edit function and before the end of playback.
@ When the link button (LINK) is pressed, will start flashing.
@ After the tracks have been played, the player will stop automatically.
The blank time of the tape val be displayed at this time.
@ Press the open/close button (4 OPEN/CLOSE) of the disc holder and
change the disc.
@ Pressing the time edit (TIME EDIT) button will permit editing using the
blank time of the tape in Step @
DERN mace eran ems at ae aoe
NOTE:
e The link operation is cancelled by the stop button ( BESTOP). It
will also be cancelled if the disc holder is opened during play.
e When editing has not been performed as far as side B with the
time edit (i.e., only for part of side A), editing will be done within
the blank time of side A and the biank time of side B.
When editing has been performed as far as side B with the time
edit, the blank time of side B will be used for editing.
® Fading Out or Fading In at the
Desired Location .................cscccsssceccsscsessssssssecereseneses
(Analog output only)
(1) Fading out and fading. in is possible at the desired position during
play (MANUAL FADER)
@ Fade Out
When the fader button (FADER) is pressed during play, fade out will be
provided for about 5 seconds. (*°£} will light up during the operation
and ( J ) will flash. When fade out is completed the player will
automatically pause.
@ Fade In
When the fader button (FADER) is pressed from the pause mode, the
player will start playing and fade in will be provided for about 3
seconds. (**) will light up during the operation and( << ) will flash.
12
2;3] 4 5 6 7 | Does not
enter :
Before the pick
ma space
After the pick
(FADER)
(2) Setting the Fade Out Time in Advance (TIME FADE)
@ When the fader button (FADER) is pressed in the stop mode, the (©)
indicator (C*°)) will light up, TIME will appear as —M—S, and the
player will wait for the input of the fade out time.
@ Input the fade out time with the (0~9) number buttons.
@ Pressing the play button ( » PLAY) will start the playback and the FADE
indicator (C=) will light up.
@ The ( t& ) indication will start flashing 5 seconds before the specified
fade out time and then the fade out will begin. The fade out will end at
the specified time and the player will automatically pause.
The time fade function will be cancelled if an auto search or manual
search is performed during playback.
( » PLAY)
(Number buttons)
(FADER)
@® To Search for the Peak Level
of the Disc .......... accbdcnbcusheccea passes ctsascdssccess cosacteresncivcevesceassees Peak Search
e The player searches for the peak portion and plays a few seconds
either side of this point repeatedly. This is convenient for making
recording adjustments on the tape recorder.
DENONG eras semwame come: sea nese asR—
(PEAK SEARCH)
@ When the peak search button (PEAK SEARCH) is pressed in the stop
mode, the PEAK indicator will flash and the player will search for the
portion having the peak level.
@ After the search, the PEAK indicator lights up and a few seconds either
side of the peak level point are played back repeatedly. This is
convenient for making recording adjustments on the tape recorder.
@) To cancel the peak search, press the stop ( HJ STOP) button.
@ When the play button { » PLAY) or the pause button ( If PAUSE) is
pressed during peak search or while playing the peak portion back
repeatedly, the player will go to the beginning of the first track (the first
track of the program for program playback, or the track that was first
selected in the time edit) and begin playback from here if the play
button was pressed or enter the pause mode if the pause button was
pressed.
NOTE:
e The peak search function reads the level of the disc from the
beginning of the disc to the end at a fixed interval and regards
the maximum value that was read as the peak.
Peak search takes a little time for this reason.
The peak portion may change each time the disc is read and
there may be a difference in the actual peak level, but since this
difference is slight it will not effect the adjustment of the record
level except with certain discs which have very long quiet
sections with only a very occasional high peak tevel. In this case
a@ manual search of the disc to find high peak is suggested.
The time fade function is cancelled when the peak search
operation is performed. To use the time fade function, set to the
stop mode then reset the function.
Buttons other than the open/close button (48 4& OPEN/CLOSE),
play button ( » PLAY), pause button ( Il PAUSE), and stop (
STOP) button will not function during peak search or repeat play
of the peak portion.
® Changing the Speed of Playback sda Cucnscuastiec€esselaceseas Save
e Playback can be speeded up or slowed down.
DENON ane mer nr cane eee
(PITCH —) (PITCH +)
@ Press the PITCH + or PITCH — button during the play or pause mode to
change the speed of playback.
@ When one of the PITCH buttons is pressed, the amount of the speed
change appears on the seconds section ("S") of the TIME display for
approximately 2 seconds. “PITCH —” appears when the speed is slower
than normal, “PITCH +" when the speed is faster than normal. The
speed can be changed in steps of 0.1% from —12.0% to +12.0%.
@ Press the PLAY button ( » PLAY) during playback with a different speed
to return to normal speed playback.
Also, the speed setting is cancelled if the stop mode is set during
playback at a different speed.
NOTES
e No data is output from the digital output jack (OPTICAL/
COAXIAL) during playback with 4 different speed (when
“PITCH” is lit). If you want to output data, press the PLAY button
( > PLAY) to return to normal speed playback.
The pitch also changes when the speed is changed.
If the speed is changed during the time edit operation, the total
playing time changes, so the time of the blank space is not
calculated accurately.
The time display (elapsed playback time, remaining time per
track, or total remaining time) will not be accurate during
playback with a different speed.
A maximum of 1 second is required to return to the normal
speed when the PLAY button ( » PLAY) is pressed during
playback with a different speed. During this time, only the
OPEN/CLOSE (45 OPEN/CLOSE) and STOP buttons ( il STOP)
will function. ,
TIMER-CONTROLLED PLAYBACK
a Operation
1. Turn on the power of all system components.
2. Set the input selector on the amplifier to correspond to the inputs
the CD player is connected to.
3. Make sure a disc has been loaded in the disc holder.
4. Check the time on the timer and-then set the desired turn-on time.
5. Turn the audio timer ON.
Power is turned off automatically in all components connected to
the timer.
6. When the preset turn-on time is reached, power is turned on in the
system components, and CD playback starts from the first track.
@ Connection
DCD-1290/ 2060/2060G
Audio Timer,
sold a aO} Power supply outlet
THE COMPACT DISC
1. Precautions on handling compact discs
e Do not allow fingerprints, oil or dust on the surface of the compact
disc. If the signal surface is dirty, wipe it off with a soft, dry cloth.
Wipe in circular motions from the center and out.
Use of DENON’s AMC-20/21 CD cleaner is recommended.
e Do.not use water, benzene, thinner, record sprays, electrostatic
proof chemicals, or silicone-treated cloth to clean discs.
e Always use care when handling discs to prevent damaging the
surface, in particular when removing a disc from the case and
returning it.
Do not bend compact discs.
Do not apply heat to compact discs.
Do not enlarge the hole in the center of the disc.
Do not write on the disc and do not attach any labels.
Condensation will form on the disc surface if it is brought into a
warm room from a cold area, such as outdoors during winter. Wait
until the condensation disappears. Never dry discs with hair dryers,
etc.
2. Precautions on storage
e After playing a disc, always return it to its case.
e Keep discs in the cases when they are not to be played. This will
protect them from dust and dirt and prolong their service life.
e Do not store discs in the following places:
1) Places exposed to direct sunlight for a considerable time.
2) Places subject to accumulation of dust or high humidity.
3) Places exposed to high temperatures, such as close to heater
outlets.
13
